Mark direction of rotation of toothed belt.

z

Loosen camshaft sprocket securing bolts (arrows), until camshaft sprocket can be moved within elongated
holes.

Fig. 78: Loosening Camshaft Sprocket Securing Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Loosen tensioning roller securing nut.

z

Turn tensioning roller counter-clockwise with two-hole pin wrench T10020 or T10004 until tensioning
roller can be locked with pin T10115. See Fig. 79 .

Fig. 79: Turning Tensioning Roller Counterclockwise With Two-Hole Pin Wrench
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn tensioning roller with two-hole pin wrench T10020 or T10004 clockwise onto limit stop and tighten
nut -1- by hand.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 80: Turning Tensioning Roller With Two-Hole Pin Wrench Clockwise Onto Limit Stop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

First remove toothed belt from coolant pump and then from remaining gears.

Installing

Requirements

z

Lock camshaft with pin 3359

z

Lock crankshaft with crankshaft stop T10050

z

Tensioning roller must be installed with pin T10115 and locked right-hand.

z

Turn camshaft gear in elongated holes to centered position (arrow).

NOTE:

Adjustment work on toothed belts must be performed on cold engines
only. The tensioning element indicator position is dependent upon the
engine temperature.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 81: Turning Camshaft Gear In Elongated Holes To Centered Position
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Place toothed belt on crankshaft pulley, tensioning roller, camshaft gear and idler roller.

z

Place toothed belt on coolant pump toothed belt gear last.

Fig. 82: Tensioning Roller Seated In Rear Toothed (Timing) Belt Guard
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Loosen tensioning roller securing nut and pull pin T10115 off.

z

Turn tensioning roller with two-hole pin wrench T10020 or T10004 clockwise until indicator aligns over
tab in base plate (arrow).

NOTE:

Make sure that tensioning roller seats correctly in rear toothed belt guard
(arrow).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 83: Turning Tensioning Roller With Two-Hole Pin Wrench
Courtesy of VOLKSWAGEN OF AMERICA, INC.

{

Ensure that securing nut does not turn.

z

Hold tensioning roller in this position and tighten tensioning roller securing nut to 20 N.m plus an
additional 45° (1/8 turn).

z

Insert counterhold T10172 with pin T10172/4 as shown in Fig. 84 . Press counterhold T10172 in
direction of arrow and hold camshaft gear to pretension.

Fig. 84: Inserting Counter-Hold With Pin
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tighten camshaft pulley securing bolts -1- in this position to 25 N.m.

z

Remove pin 3359 and crankshaft stop T10050.

z

Turn crankshaft two rotations in engine direction of rotation until crankshaft is set just before TDC No. 1
cylinder.

z

Unlock hub with pin 3359 out of engine in direction of rotation.
