z

Remove engine cover.

{

Pull front of engine cover abruptly upward (arrow -A-) and then pull forward out of rear securing
elements (arrow -B-).

z

Remove poly V-belt. See POLY V-BELT, REMOVING AND INSTALLING .

z

Remove poly V-belt tensioning element.

z

Remove coolant expansion tank (coolant hoses remain connected).

z

Remove fuel filter retaining plate.

Fig. 71: Removing Engine Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install engine support bracket 10-222A and take up weight of engine in its installed position.

Fig. 72: Installing Engine Support Bracket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

temperature.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



z

Remove securing bolts from assembly mounting/engine mounting, assembly mounting/body and
assembly mounting/body mounting (arrows) and remove assembly mounting complete.

Fig. 73: Removing Securing Bolts From Engine Mounts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove toothed belt guard upper part.

z

Remove lower charge air pipe -1-.

{

Remove bolt/screw -2- and release connector (arrow).

Fig. 74: Removing Lower Charge Air Pipe And Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

z

Remove engine mounting when the engine is secured with the
support bracket 10-222A.

z

The engine mounting may only be loosened if the assembly
mounting has been removed.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



{

Carefully cover or close open ends.

z

Remove center and right side sound insulation.

z

Unbolt engine mounting on cylinder block (arrows) and remove.

Fig. 75: Removing Engine Mounting On Cylinder Block
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove vibration damper/belt pulley.

z

Remove lower and middle toothed belt guards.

z

Set crankshaft to TDC No. 1 cylinder.

NOTE:

z

When loosening both upper engine mounting bolts the engine must
be raised slightly with the support bracket.

z

When loosening the front engine mounting bolt the engine must be
raised slightly with the support bracket.

NOTE:

z

The engine may only be turned over using the crankshaft.

z

Turn crankshaft in direction of rotation until the marks on the crankshaft
toothed (timing) belt sprocket are at the top and (arrow) "4Z" -2- on the
toothed belt guard is aligned behind the tabs -1- of the wheel sensor.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



z

Lock hub using locking pin 3359. To do this, slide locking pin through free elongated hole on left side
and into hole in cylinder head.

z

Lock crankshaft toothed belt gear using crankshaft stop T10050. To do this, slide crankshaft stop into
teeth of sprocket from front of gear.

Fig. 77: Aligning Marks On Crankshaft Toothed (Timing) Belt Gear And On Crankshaft Stop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Fig. 76: Aligning Crankshaft Toothed (Timing) Belt Sprocket On Toothed
Belt Guard
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

In the illustration the camshaft toothed gear is shown without the toothed
belt.

NOTE:

Marks on crankshaft toothed belt gear -2- and on crankshaft stop -1- must
align with one another. The pin of the crankshaft stop must engage in the
hole in the sealing flange.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)
