Volkswagen New Beetle. Manual - part 990





z

With bracket for engine cover

22. Cylinder head gasket

z

Always replace

z

Note marking. See Fig. 61

z

After replacing, replace entire coolant

23. 20 N.m

24. Cylinder head

z

Check for distortion. See Fig. 60

z

Removing and installing. See CYLINDER HEAD, REMOVING AND INSTALLING .

z

After replacing, replace entire quantity of coolant.

25. 10 N.m

z

Always replace

26. Camshaft Position (CMP) Sensor-G40-

z

For camshaft position

z

To remove, unclip sealing grommet from rear toothed belt guard

27. Glow plug

z

15 N.m

z

Checking. See GLOW PLUGS, CHECKING .

28. Unit injector

z

Removing and installing. See INJECTOR UNIT, REMOVING AND INSTALLING .

29. Cylinder head bolt

z

Note sequence when loosening and tightening. See CYLINDER HEAD, REMOVING AND
INSTALLING
 .

z

Before installing, set washers in cylinder head. See SPECIAL TOOLS AND EQUIPMENT .
item 4, Servicing valve gear



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 59: Exploded View Of Cylinder Head Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Cylinder head distortion, checking

Fig. 60: Checking Cylinder Head Distortion
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Special tools and equipment

z

Straight edge



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



z

Feeler gauges

Max. permissible distortion: 0.1 mm (minimum distance between linear measurements: 100 mm)

Cylinder head gasket identification

Fig. 61: Identifying Cylinder Head Gasket Control Code And Hole
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Part No. = arrow -1-

z

Control code = arrow -2- (not significant!)

z

Hole(s) = arrow -3-

Cylinder head cover, removing and installing

Special tools and equipment

NOTE:

Reworking diesel cylinder heads is not permissible.

NOTE:

Different thicknesses of cylinder head gasket are installed depending on the
piston projection dimension. When replacing the cylinder head gasket, install a
new gasket with the same identification.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 62: Identifying Special Tools And Equipment (V.A.G 1331)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

V.A.G 1331 Torque wrench (5 to 50 N.m)

z

Sealant AMV 174 004 01

Removing

z

Remove engine cover.

Fig. 63: Removing Engine Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

{

Pull front engine cover abruptly upward (arrow -A-) and then pull forward out of rear securing
elements (arrow -B-).

z

Remove exhaust gas recirculation valve. See EGR VACUUM REGULATOR SOLENOID VALVE -
N18-,REMOVING AND INSTALLING
 .

z

Remove toothed belt guard upper part.

z

Separate crankcase breather hose at union on rear charge air pipe.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)
