z

Remove cylinder head cover.

Installing

Installation is performed in reverse sequence of removal. Note the following:

z

Thoroughly clean sealing surfaces using clean cloth.

z

Apply a drop of sealant AMV 174 004 01 (diameter approx. 5 mm) to both forward edges of bearing
cap/cylinder head sealing surface (arrows).

Fig. 64: Identifying Forward Edges Of Bearing Cap/Cylinder Head Sealing Surface
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Apply a drop of sealant AMV 174 004 01 (diameter approx. 5 mm) to both back edges of bearing
cap/cylinder head sealing surface (arrows).

Fig. 65: Identifying Back Edges Of Bearing Cap/Cylinder Head Sealing Surface

NOTE:

Replace cylinder head cover and seals for bolts if damaged.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Position cylinder head.

z

Tighten cylinder head cover bolts hand tight in sequence -1- to -13-.

z

Tighten bolts in sequence -1- to -13- to 10 N.m.

Fig. 66: Cylinder Head Cover Bolt Tightening Sequence
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install exhaust gas recirculation valve. See EGR VACUUM REGULATOR SOLENOID VALVE -
N18-,REMOVING AND INSTALLING
 .

Toothed belt, removing and installing

Special tools and equipment

z

3359 Pin

z

T10004 Two-hole pin wrench (or T10020)

z

T10115 Pin

z

T10050 Crankshaft stop

z

V.A.G 1331 Torque wrench (5 to 50 N.m)

z

V.A.G 1332 Torque wrench (40 to 200 N.m)

z

10-222A support element with adapter 10-222A/8 (modifying guide 10-222 A/21. See MODIFYING
GUIDE 10-222 A/21 FROM SUPPORT DEVICE 10-222 A
 .

z

T10004 Two-hole pin wrench (or T10020)

z

T10172 Counter-bracket

z

T10172/4 Pin



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 67: Identifying Special Tools And Equipment (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Fig. 68: Identifying Special Tools And Equipment (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Modifying guide 10-222 A/21 from support device 10-222 A

NOTE:

A new tensioning roller is gradually being introduced. The tensioning roller has
an additional hex bit (arrow). Use a hex key to tighten/loosen toothed belt
instead of the two-hole pin wrench T10020 or T10004. This does not change the
work sequence.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 69: Identifying Revised Tensioning Roller
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Support device 10-222A is required to support engine/transmission assembly.

A new hole is required on guide 10-222 A/21 to secure adapter 10-222 A/8.

Fig. 70: Identifying Guide
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Dimensions given are in mm.

z

Drill a 12.5 mm diameter hole (arrow) in guide 10-222 A/21.

Removing

NOTE:

Adjustment work on toothed belts must be performed on cold engines only. The
tensioning element indicator position is dependent upon the engine



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)
