Fig. 49: Disassembling And Assembling View Of Pistons And Connecting Rods
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking piston ring gap

Fig. 50: Checking Piston Ring End Gap
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Special tools and equipment

z

Feeler gauges

z

Push ring down squarely from above to approx. 15 mm from bottom end of cylinder.

z

1 gap with feeler gauge.

RING GAP DETERMINING

Checking ring to groove clearance

Piston ring end gap (in mm)

New

Wear limit

1. Compression ring

0.20 to 0.40

1.0

2. Compression ring

0.20 to 0.40

1.0

Oil scraper ring

0.25 to 0.50

1.0



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 51: Checking Ring To Groove Clearance
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Special tools and equipment

z

Feeler gauges

z

Clean ring groove before checking.

z

Determine clearance with feeler gauge.

RING TO GROOVE CLEARANCE

Cylinder bores, checking

Special tools and equipment

z

Internal dial gauge 50 to 100 mm

z

Take measurements at 3 positions in both lateral -A- and longitudinal -B- planes, as illustrated. Deviation
from nominal dimension max. 0.10 mm

Piston ring to groove ( in mm)

New

Wear limit

1. Compression ring

0.06 to 0.09

0.25

2. Compression ring

0.05 to 0.08

0.25

Oil scraper ring

0.03 to 0.06

0.15



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 52: Checking Cylinder Bores Dimensions
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Piston installed position and piston/cylinder application

Piston in cylinders 1 and 2:

Larger intake valve chamber toward flywheel (arrows). See Fig. 53 .

Fig. 53: Locating Larger Intake Valve Chamber Toward Flywheel And Belt Pulley Side
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Piston in cylinders 3 and 4:

Larger intake valve chamber toward belt pulley side (arrows).

NOTE:

Measuring the cylinder bores must not be done when the cylinder block is
mounted on a repair stand with adapter bracket VW 540, as incorrect
measurements would be possible.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Installed position of bearing shells

Fig. 54: Identifying Connecting Rod Bearing Cap Shells Dimension -a-
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Center bearing shells when inserting into connecting rod and connecting rod bearing cap.

Dimension -a- must be equal on both left and right sides

Max. deviation: 0.2 mm

Piston projection at TDC, checking

Special tools and equipment

z

VW 382/7 Measuring device

NOTE:

New piston/cylinder allocations are shown by a colored marking on the piston
crown.

z

Piston for cylinder 1 and 2: marked 1/2

z

Piston for cylinder 3 and 4: marked 3/4



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)
