Volkswagen New Beetle. Manual - part 987





Special tools and equipment

z

Kukko 21/2 and Kukko 22/1

z

3176 Centering mandrel

or

z

Mandrel 207 c

Fig. 45: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Pull off with extractor -A-, e.g. Kukko 21/2 and Kukko 22/1.

NOTE:

Check whether the needle bearing is installed in the crankshaft when installing
the engine. Install the needle bearing, if necessary.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 46: Removing Needle Bearing From Crankshaft Using Extractor
Courtesy of VOLKSWAGEN OF AMERICA, INC.


Installing

z

Drive in using punch 207c or centering mandrel 3176.

z

Inscription side of needle bearing must be able to be read when it is installed

Fig. 47: Driving In Needle Bearing Using Punch 207C
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Locating distance of needle bearing

z

Dimension a = 1.7 mm +/- 0.5 mm

Fig. 48: Locating Needle Bearing Installed Distance
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Crankshaft dimensions



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



CRANKSHAFT DIMENSIONS

PISTONS AND CONNECTING RODS, DISASSEMBLING AND ASSEMBLING

1. Piston rings

z

Offset ring gaps by 120°

z

Position oil scraper ring gap in tight winded spring area

z

Use piston ring pliers to remove and install

z

"TOP" faces toward piston crown

z

Checking ring gap. See Fig. 50

z

Checking ring to groove clearance. See Fig. 51

2. Piston

z

With combustion chamber

z

Mark installation position and cylinder number.

z

Mark installation position and application piston/cylinder. See Fig. 53

z

Arrow on piston crown points to belt pulley end.

z

Install using piston ring clamp.

z

Cracks on piston skirt, replace piston

z

Checking piston projection at TDC. See PISTON PROJECTION AT TDC, CHECKING

3. Piston pin

z

If difficult to remove, heat piston to 60 °C

z

Remove and install with drift VW 222a

4. Circlip

NOTE:

For CRANKSHAFT DIMENSIONS , all dimensions are in mm.

Honing dimension

Main journal diameter

Connecting rod journal diameter

Basic dimension

-0.022

54.00

-0.042

-0.022

47.80

-0.042

1st undersize

-0.022

53.75

-0.042

-0.022

47.55

-0.042

2nd undersize

-0.022

53.50

-0.042

-0.022

47.30

-0.042

3rd undersize

-0.022

53.25

-0.042

-0.022

47.05

-0.042

NOTE:

The following list refers to items in Fig. 49 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



5. Connecting rod

z

Mark cylinder number -A- with colored pen

z

Installed position: Marking -B- faces pulley end

z

With industrially cracked bearing caps.

6. Bearing shell

z

Note installed position. See Fig. 54

z

Note versions:

z

Upper bearing shell (to piston) made out of more hard-wearing material

z

Distinguishing features: Black line on contact surface in separating area

z

Do not interchange used bearing shells.

z

Insert bearing shells centrally. See Fig. 54

z

Check for secure seating

z

Axial clearance. Wear limit: 0.37 mm

z

Check radial clearance with Plastigage, Wear limit: 0.08 mm

z

Do not rotate crankshaft when checking radial clearance

7. Cylinder block

z

Checking cylinder bores. See Fig. 52

z

Piston and cylinder dimensions. See PISTON AND CYLINDER DIMENSIONS

8. Connecting rod bearing cap

z

Note installed position.

z

Caps only install in one position and only on appropriate connecting rod due to breaking procedure
(industrially cracking) separating cap from connecting rod

9. Oil spray jet

z

For piston cooling.

10. 25 N.m

z

Insert without sealant

11. Connecting rod bolt, 30 N.m plus an additional 1/4 turn (90°)

z

Always replace

z

Oil threads and contact surfaces.

z

To measure radial clearance use old bolts



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)
