Volkswagen New Beetle. Manual - part 985





z

To guide seal extractor, screw center bolt into crankshaft onto limit stop by hand.

z

Unscrew inner part of oil seal extractor 3203 nine turns (approx. 17 mm) out of outer part and lock with
knurled screw.

z

Lubricate threaded head of oil seal extractor, place it in position and exerting firm pressure screw it into
oil seal as far as possible.

z

Loosen knurled screw and turn inner part against crankshaft until oil seal is pulled out.

Fig. 34: Loosening Knurled Screw And Turn Inner Part Against Crankshaft To Remove Oil Seal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Remove oil residue from crankshaft journal using clean cloth.

z

Install guide sleeve T10053/1 onto crankshaft journal.

installing the counterhold.

NOTE:

The oil seal sealing lip must not be oiled or greased.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 35: Installing Guide Sleeve Onto Crankshaft Journal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Slide oil seal over guide sleeve onto crankshaft journal.

z

Press in oil seal using press sleeve T10053 and screw T10053/2 (M16 x 1.5 x 60) onto stop.

Fig. 36: Installing Crankshaft Toothed Belt Pulley With NEW Center Bolt
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install crankshaft toothed belt pulley with new center bolt.

z

Install toothed belt. See TOOTHED BELT, REMOVING AND INSTALLING .

Sealing flange - belt pulley end, removing and installing

Special tools and equipment

z

3099 Counterhold

z

T10053 Assembly device

z

V.A.G 1331 Torque wrench (5 to 50 N.m)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



z

V.A.G 1332 Torque wrench (40 to 200 N.m)

z

Hand drill with plastic brush attachment

z

D 176 04 A2 Silicone sealant

z

Flat scraper

Fig. 37: Checking Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove toothed belt. See TOOTHED BELT, REMOVING AND INSTALLING .

z

Remove crankshaft toothed belt gear. To do this counterhold gear with 3099.

Fig. 38: Removing Crankshaft Toothed (Timing) Belt Gear
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

When installing the counterhold, place two washers between toothed belt
gear and counter bracket.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



z

Drain engine oil.

z

Remove oil pan. See OIL PAN, REMOVING AND INSTALLING .

z

Unbolt sealing flange.

z

Remove sealing flange. Release using light blows with a rubber-headed hammer if necessary.

z

Remove sealant residue on cylinder block with a flat scraper.

z

Remove sealant remains on sealing flange with a rotating plastic brush (wear eye protection).

Fig. 39: Removing Sealant Remains On Sealing Flange With Rotating Plastic Brush
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Clean sealing surfaces. They must be free of oil and grease.

Installing

z

Remove oil residue from crankshaft journal using clean cloth.

z

Cut off tube nozzle at front marking (nozzle approx. 3 mm diameter).

NOTE:

z

Observe the use-by date of the sealing compound.

z

The sealing flange must be installed within 5 minutes after applying the
silicone sealant.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)
