Volkswagen New Beetle. Manual - part 983





Fig. 23: Identifying Alternator & Power Steering Pump Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Part III

1. Cylinder block

z

Removing and installing sealing flange and flywheel. See SEALING FLANGES AND
FLYWHEEL, REMOVING AND INSTALLING


z

Removing and installing crankshaft. See CRANKSHAFT, REMOVING AND INSTALLING

z

Disassembling and assembling pistons and connecting rods. See PISTONS AND CONNECTING
RODS, DISASSEMBLING AND ASSEMBLING


2. 3.5 N.m

3. Bracket

z

For vacuum reservoir

4. Vacuum reservoir

5. 40 N.m

6. Seal

z

Always replace

7. Oil filter bracket

z

Disassembling and assembling. See PART 2: DISASSEMBLING OIL FILTER BRACKET

8. 15 N.m plus an additional 1/4 turn (90°)

z

Always replace

z

First install upper left and lower right bolt, then tighten four bolts diagonally

9. 15 N.m

10. Engine Speed (RPM) sensor -G28-

11. Connection union

NOTE:

The following list refers to items in Fig. 24 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



z

For thermostat

12. O-ring

z

Always replace

13. Thermostat

z

Removing and installing. See THERMOSTAT, REMOVING AND INSTALLING .

z

Observe installation position. See THERMOSTAT, REMOVING AND INSTALLING ,
removing and installing thermostat

z

Checking: Heat-up thermostat in water.

z

Starts to open: approx. 85 °C

z

Ends: approx. 105 °C

z

Opening stroke: min. 7 mm

14. 45 N.m

z

Note tightening sequence. See Tightening sequence for compact bracket to cylinder block

15. Compact bracket

z

For Generator, air conditioning compressor and power steering pump

16. Oil pan

z

Clean sealing surface before installing.

z

Install with silicone sealant D 176 404 A2. See OIL PAN, REMOVING AND INSTALLING

Fig. 24: Identifying External Engine Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Tightening sequence for compact bracket to cylinder block

Tightening Sequence For Compact Bracket To Cylinder Block

Work sequence

z

Install compact bracket to cylinder block (observe dowel sleeves between compact bracket and cylinder



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



block).

z

Tighten compact bracket in tightening sequence as follows:

1. Tighten bolt -A- to 45 N.m.

2. Tighten bolt -B- to 45 N.m.

3. Tighten bolt -C- to 45 N.m.

4. Tighten bolt -D- to 45 N.m

5. Tighten bolt -E- to 45 N.m.

6. Tighten bolt -F- to 45 N.m.

Fig. 25: Tightening Sequence For Compact Bracket To Cylinder Block
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Poly V-belt, removing and installing

Special tools and equipment

z

T10060 Mandrel

NOTE:

The following list refers to items in Fig. 25 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 26: Identifying Special Tools And Equipment (Mandrel)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove upper charge air line -1- with connecting hose -2-.

z

Remove bolt/screw -3- and release connector (arrow).

Fig. 27: Removing Upper Charge Air Line -1- With Connecting Hose
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Carefully cover or close open ends.

z

Mark direction of rotation of poly V-belt.

z

Turn tensioning element in direction of arrow to relieve tension on poly V-belt and lock with mandrel
T10060.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)
