Volkswagen New Beetle. Manual - part 981





Fig. 16: Identifying Transmission Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.

ASSEMBLY MOUNTINGS

Tightening torques

Engine mounting

1. Mounting to body. ALWAYS replace torque to yield bolts.

40 N.m plus 90° (1/4 turn)

2. Mounting/bracket to - body

25 N.m

3. Mounting to engine - mounting

100 N.m

NOTE:

Footnote 1 in Fig. 17 : ALWAYS replace torque to yield bolts.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 17: Replacing Engine Mounting Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Transmission mounting

1. Mounting to body. ALWAYS replace torque to yield bolts.

40 N.m plus 90° (1/4 turn)

2. Mounting to body

25 N.m

3. Mounting to transmission console

100 N.m

NOTE:

Footnote 1 in Fig. 18 : ALWAYS replace torque to yield bolts.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 18: Replacing Transmission Mounting Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pendulum support

Installation sequence

1. Pendulum support to subframe. ALWAYS replace torque to yield bolts.

20 N.m plus 90° (1/4 turn)

2. Pendulum support to transmission. ALWAYS replace torque to yield bolts.

40 N.m plus 45° (1/8 turn)

3. Pendulum support to transmission. ALWAYS replace torque to yield bolts.

40 N.m plus 45° (1/8 turn)

NOTE:

Footnote 1 in Fig. 19 : ALWAYS replace torque to yield bolts.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 19: Installing Pendulum Support Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

ADDITIONAL NOTES AND ASSEMBLY STEPS FOR VEHICLES WITH AIR CONDITIONING

To remove and install engine without opening refrigerant circuit:

z

Remove Generator.

See GENERATOR .

z

Remove dipstick guide funnel if necessary.

z

Remove air conditioning compressor

See CONDENSER, REMOVING AND INSTALLING .

z

Secure A/C compressor to lock carrier so that refrigerant lines/hoses are not stressed.

CAUTION: Do not open refrigerant circuit for A/C system.

NOTE:

Do not bend or stretch lines or hoses as condenser and/or refrigerant
lines/hoses may be damaged.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)
