Fig. 20: Identifying A/C Compressor And Refrigerant Lines/Hoses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

ENGINE CRANKSHAFT, CYLINDER BLOCK

ENGINE, DISASSEMBLING AND ASSEMBLING

I. See PART I

II. See PART II

III. See PART III

NOTE:

If large quantities of metal particles or other deposits (caused, for example, by
partial seizure of the crankshaft or connecting rod bearings) are found in the
engine oil, the oil passages must be cleaned thoroughly and the oil cooler
replaced in order to prevent further damage.

NOTE:

The following list refers to items in Fig. 21 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 21: Disassembling And Assembling View Of Engine
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Part I

1. Toothed belt guard, upper part

2. Toothed belt

z

Mark direction of rotation before removing

z

Check for wear

z

Do not kink

z

Removing, installing and tensioning. See TOOTHED BELT, REMOVING AND INSTALLING

3. 20 N.m plus an additional 1/8turn (45°)

4. Tensioning roller

5. 100 N.m

6. 25 N.m

7. Camshaft pulley

8. Hub

z

With sender wheel

z

Use counter-bracket T10051 to loosen and tighten

z

Use puller T10052 to remove

z

installing and removing. See CAMSHAFT, REMOVING AND INSTALLING , removing and
installing camshaft

9. 10 N.m

z

Always replace

10. Rear toothed belt guard

11. Sealing grommet

NOTE:

The following list refers to items in Fig. 22 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



z

Replace if damaged.

12. Idler roller

13. Coolant pump

z

Removing and installing. See COOLANT PUMP, REMOVING AND INSTALLING .

14. Crankshaft toothed belt gear

15. 120 N.m plus an additional 1/4 turn (90°)

z

Always replace

z

Additional turn can be done in several stages

z

Counterhold with 3099 to loosen and tighten.

z

Do not add oil or grease to threads and shoulder

16. 15 N.m

17. 20 N.m

18. Toothed belt guard, lower part

19. Belt pulley/vibration damper

z

Can only be installed in one position. Holes are offset

20. 10 N.m plus an additional 1/4 turn (90°)

21. Cover

22. Toothed belt guard, center section

23. 45 N.m

24. Engine bracket

Fig. 22: Identifying Engine Front Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Part II

NOTE:

The following list refers to items in Fig. 23 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



1. Poly V-belt

z

Mark direction of rotation before removing

z

Check for wear

z

Do not kink

z

Removing and installing. See POLY V-BELT, REMOVING AND INSTALLING

2. 10 N.m plus an additional 1/4 turn (90°)

3. Belt pulley/vibration damper

z

Can only be installed in one position. Holes are offset

4. 25 N.m

5. Tensioning element for poly V-belt

z

Turn with open end wrench to loosen ribbed belt. See POLY V-BELT, REMOVING AND
INSTALLING


6. Generator

7. Compact bracket

z

For Generator, air conditioning compressor and power steering pump

8. 45 N.m

z

Note tightening sequence. See Tightening sequence for compact bracket to cylinder block .

9. Banjo bolt, 30 N.m

10. Seal

z

Always replace

11. Pressure line

12. Power steering pump

z

For power steering

z

Removing and installing:

See POWER STEERING PUMP: VEHICLES WITH POWER STEERING PUMP IN LOWER
SECTION, REMOVING AND INSTALLING
 .

13. Belt pulley

z

For power steering pump



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)
