Volkswagen New Beetle. Manual - part 980





Fig. 12: Attaching Engine To Assembly Stand
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lower engine/transmission assembly so that transmission is supported by work bench.

z

Remove engine/transmission connecting bolts.

z

Push transmission off engine.

z

Attach lifting tackle 2024A as follows and lift off engine/transmission jack V.A.G 1383 A using
workshop crane.

Fig. 13: Attaching Lifting Tackle And Lift Off Engine/Transmission Jack
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Belt pulley end: 2nd hole on support bar in position 1

z

Flywheel end: 4th hole on support bar in position 8

WARNING:

Secure ALL hooks and locating pins with lock pins!

NOTE:

z

Positions marked 1 to 4 on the bar must face toward the pulley end of
the engine.

z

The holes in the hook rails are counted up from the hook.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



z

Secure engine to holding fixture VW 313 using engine and transmission support VW 540 and
supplementary set VW 540/1B.

NOTES ON INSTALLING

Installation is performed in reverse order. Note following:

z

Install intermediate plate onto sealing flange slide onto dowel sleeves (arrows).

Fig. 14: Installing Intermediate Plate Onto Sealing Flange And Slide Onto Dowel Sleeves
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lightly grease input shaft splines with G 000 grease.

z

When installing, make sure that clearance exists between surrounding components.

z

Align engine and transmission mountings. See ENGINE AND TRANSMISSION MOUNTINGS,
ALIGNING
 .

Tightening torques. See ASSEMBLY MOUNTINGS , assembly mountings.

z

Install axle shafts:

NOTE:

First loosen coolant pipe on flywheel end.

CAUTION: When performing repair work, especially due to the confined conditions in

the engine compartment, pay attention to the following.

z

Route all types of hoses/lines (e.g. for fuel, hydraulics, EVAP system,
coolant, refrigerant brake fluid and vacuum) as well as electrical
wiring so that the original positions are restored.

z

Ensure sufficient clearance to all moving hot components.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



See FRONT AXLE SHAFT .

z

Install front exhaust pipe. See FRONT EXHAUST PIPE AND CATALYST WITH COMPONENTS

z

Install assembly.

See SUBFRAME .

z

Install selector lever cable.

See SELECTOR LEVER CABLE .

z

Installing power steering pump:

See POWER STEERING PUMP WITH HYDRAULIC LINES/HOSE .

z

Check electrical connections and routing:

Vehicles with air conditioning

z

Install Generator.

See GENERATOR .

z

Install air conditioning compressor:

See CONDENSER, REMOVING AND INSTALLING .

Continued for all vehicles

z

Install poly V-belt. See POLY V-BELT, REMOVING AND INSTALLING .

z

Fill with coolant. See COOLANT, DRAINING AND FILLING .

z

Install center, left and right sound insulation trays:

See NOISE INSULATION, ASSEMBLY OVERVIEW .

z

Perform a road test and check Diagnostic Trouble Code (DTC) memory. See ENGINE CONTROL
MODULE (DTC) MEMORY, READING AND ERASING
 .

TIGHTENING TORQUES

TIGHTENING TORQUES

Threaded connection

(1)

 Torque setting

Bolts, nuts

M6

10 N.m

M7

15 N.m



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



ENGINE AND TRANSMISSION MOUNTINGS, ALIGNING

Engine mounting clearances. See Fig. 15 .

a = 14.0 mm

b = At least 10.0 mm

Both bolt heads -1- must be in flush with edge -c-.

Fig. 15: Identifying Engine Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Transmission mounting clearances. See Fig. 16 .

Edges -a- and -b- must be parallel with one another.

c = 18 to 20 mm

M8

25 N.m

M10

40 N.m

M12

60 N.m

(1)

Deviations from above: Engine to transmission connecting bolts. See TRANSMISSION .

NOTE:

Tightening torques for assembly mounting. See ASSEMBLY MOUNTINGS .

WARNING:

Before loosening the bolts, the assembly must be supported with support
bar 10-222A.
