Volkswagen New Beetle. Manual - part 979





Fig. 6: Identifying Center And Left And Right Side Sound Insulation
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Drain coolant. See COOLANT, DRAINING AND FILLING .

z

Remove rear coolant hose from oil cooler.

z

Remove radiator coolant hoses from engine using hose clip pliers V.A.G 1921 or VAS 5024.

z

Remove wiring harness from Generator and lay to one side.

z

Disconnect all electrical wiring from transmission and starter and move clear.

z

Tie power steering reservoir on lock carrier.

z

Remove fuel supply hose -1- and fuel return hose -2- from fuel lines on cylinder head.

z

Remove poly V-belt. See POLY V-BELT, REMOVING AND INSTALLING .

z

Remove selector lever cable.

See SELECTOR LEVER CABLE .

z

Remove all other inter-connecting, coolant, vacuum and intake hoses on engine.

z

Remove/disconnect all electrical connections as necessary from engine and lay to one side.

WARNING:

z

The fuel and the fuel lines in the fuel system can become very hot
(danger of scalding.)

z

The fuel system is also under pressure! Before opening the system,
place cloths around the connections. Then carefully loosen the
connection to release pressure.

z

Wear eye and hand protection when performing any type of repair
work on the fuel system!



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 7: Removing Fuel Supply Hose And Fuel Return Hose
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove right side axle shaft and disconnect left side axle shaft at transmission:

See FRONT AXLE SHAFT .

z

Remove securing clamps for power steering pressure line.

z

Remove power steering pump from bracket place to side; hoses remain connected:

See POWER STEERING PUMP WITH HYDRAULIC LINES/HOSE .

z

Removing subframe:

See SUBFRAME .

z

Remove front exhaust pipe. See FRONT EXHAUST PIPE AND CATALYST WITH
COMPONENTS
 .

z

Unbolt pendulum support in stated sequence (arrow).

Fig. 8: Removing Pendulum Support
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Vehicles with air conditioning

z

Observe additional information and removal. See ADDITIONAL NOTES AND ASSEMBLY STEPS
FOR VEHICLES WITH AIR CONDITIONING
 .

Continued for all vehicles

z

Insert engine bracket T10012 in engine/transmission jack V.A.G 1383 A.

Fig. 9: Inserting Engine Bracket In Engine/Transmission Jack
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove bracket on cylinder block for lower coolant hose. Threaded hole is required to secure engine
bracket T10012.

z

Secure engine bracket T10012 to cylinder block with securing nuts and bolt M10 X 25 / 8.8 to N.m.

z

Lift engine and transmission lightly using engine/transmission jack V.A.G 1383 A.

z

Unbolt top of engine bracket (arrows) on engine mounting.

Fig. 10: Removing Top Of Engine Bracket On Engine Mounting



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unbolt top of transmissions bracket (arrows -B-) on transmission mounting.

Fig. 11: Removing Top Of Transmissions Bracket On Transmission Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Carefully lower engine and transmission.

z

While lowering, guide power steering pressure line past transmission.

ENGINE, ATTACHING TO ASSEMBLY STAND

Work sequence

z

Transfer engine/transmission subassembly to workbench via engine/transmission jack VAG 1383 A.

NOTE:

To remove securing bolts, use step ladder VAS 5085.

NOTE:

The engine and transmission must be guided carefully when lowering to
prevent damage to the body.

NOTE:

To work on the engine outside of the vehicle, attach the engine to an assembly
stand using the VW 313 holding fixture along with the VW 540
engine/transmission support.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)
