Volkswagen New Beetle. Manual - part 984





Fig. 28: Turning Tensioning Element In Direction Of Arrow To Relieve Tension On Poly V-Belt
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove ribbed belt.

Installing

z

Installation is performed in reverse sequence of removal.

After completing repairs:

z

Start engine and check belt running.

Drive belt with no air conditioner compressor

NOTE:

z

Before installing poly V-belt, make sure that all ancillaries (Generator, air
conditioner compressor, power steering pump) are secured tightly.

z

When installing poly V-belt, check direction of rotation and proper seating
of belt in belt pulleys.

z

For vehicles which do not have an air conditioning system: place ribbed
belt over Generator pulley last.

z

For models with an air conditioning system: place poly V-belt over A/C
compressor last.

z

When installing upper charge air line lift line connection piece on charge
air cooler slightly (engages easier).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 29: Identifying Drive Belt Routing With No Air Conditioner Compressor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Drive belt with A/C compressor (double poly V-belt)

Fig. 30: Identifying Drive Belt Routing With A/C Compressor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

SEALING FLANGES AND FLYWHEEL, REMOVING AND INSTALLING

1. Seal

z

Do not add oil or grease oil seal sealing lip

z

Before installing, remove oil residue from crankshaft journal using a clean cloth

z

Replacing crankshaft oil seal, poly V-belt pulley end. See CRANKSHAFT OIL SEAL -
PULLEY END, REPLACING


2. Sealing-flange belt pulley end

NOTE:

The following list refers to items in Fig. 31 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



z

Must be located on dowel sleeves.

z

Removing and installing. See SEALING FLANGE - BELT PULLEY END, REMOVING AND
INSTALLING
 .

z

Insert with silicone sealant D 176 404 A2. See SEALING FLANGE - BELT PULLEY END,
REMOVING AND INSTALLING
 .

3. Cylinder block

z

Removing and installing crankshaft. See CRANKSHAFT, REMOVING AND INSTALLING

z

Disassembling and assembling pistons and connecting rods. See PISTONS AND CONNECTING
RODS, DISASSEMBLING AND ASSEMBLING
 .

4. Flywheel

z

To remove and install flywheel counterhold with 3067

5. 60 N.m plus an additional 1/4 turn (90°)

z

Always replace

6. Intermediate plate

z

Must be located on dowel sleeves

z

Do not damage/bend when assembling

7. 15 N.m

8. Sealing flange with oil seal

z

Replace complete

z

Do not add oil or grease to oil seal sealing lip

z

Before installing, remove oil residue from crankshaft journal using a clean cloth

z

Use protective sleeve supplied when installing

z

Remove protective sleeve first after sliding sealing flange onto crankshaft journal

Fig. 31: Removing And Installing Sealing Flanges And Flywheel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Crankshaft oil seal - pulley end, replacing



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Special tools and equipment

z

3099 Counterhold

z

3203 Oil seal extractor

z

T10053 Assembly device

z

V.A.G 1331 Torque wrench (5 to 50 N.m)

z

V.A.G 1332 Torque wrench (40 to 200 N.m)

Fig. 32: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove toothed (timing) belt. See TOOTHED BELT, REMOVING AND INSTALLING .

z

Remove crankshaft toothed belt gear. To do this counterhold gear with 3099.

Fig. 33: Removing Crankshaft Toothed (Timing) Belt Gear
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

Place two washers between toothed belt gear and counter bracket when



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)
