Fig. 85: Checking Whether Crankshaft Can Be Locked With Crankshaft Stop T10050
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check whether crankshaft can be locked with crankshaft stop T10050.

If crankshaft will not lock:

z

Loosen camshaft pulley securing bolts (arrows).

Fig. 86: Loosening Camshaft Pulley Securing Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn crankshaft slightly against engine direction of rotation until crankshaft stop pin is positioned just
before hole in sealing flange (arrow).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 87: Turning Crankshaft Against Engine Direction Of Rotation Until Crankshaft Stop Pin Is
Positioned Just Before Hole In Sealing Flange
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn crankshaft in engine direction of rotation until crankshaft stop pin engages in sealing flange while
turning.

z

Insert counterhold T10172 with pin T10172/4 as shown. Press counterhold T10172 in direction of (arrow)
and hold camshaft gear to pretension.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



Fig. 88: Inserting Counter-Hold With Pin
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tighten camshaft pulley securing bolts -1- in this position to 25 N.m.

z

Remove pin 3359 and crankshaft stop T10050.

z

Turn crankshaft two rotations in engine direction of rotation until crankshaft is set just before TDC No. 1
cylinder.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 1.9L 4-Cyl. (Engine Code BEW)



z

Repeat check.

z

Install toothed belt guard center and lower parts.

z

Install belt pulley/vibration damper.

Tightening torque: 10 N.m plus an additional 90° (1/4 turn)

z

Install engine mounting to cylinder block and tighten (arrows).

Tightening torque: 45 N.m

NOTE:

z

Insert bolts into engine bracket before installing engine bracket.

z

Before installing the assembly mounting, all engine mounting bolts must
be tightened to prescribed torque.
