z

Request radio code on vehicles with coded radio.

z

Disconnect battery.

z

Pry off cover cap -1- and remove screws -2-.

Fig. 69: Prying Off Cover Cap And Removing Screws
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Take switch mounting -3- off bracket.

z

Release cover -1- from rear of instrument panel and pull off.

Fig. 70: Releasing Cover From Rear Of Instrument Panel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove screw -2- and screws -3-.

z

Turn rotary knob -1- of lighting switch to 0 position.

z

Press rotary knob inward -arrow A- and turn to the right -arrow B-.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 71: Pressing Rotary Knob Inward And Turning To Right
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect switch out of instrument panel -arrow C- and disconnect connector.

z

Unclip headlight range control switch -2- and disconnect connector.

z

Remove screw (under a cover cap) -arrow- from glove box -1-.

Fig. 72: Removing Screw From Glove Box
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove the four screws -1-.

z

Unclip trim -2- at top and take off instrument panel.

z

Remove the six screws -3-.

z

Remove impact plate -4-.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 73: Removing Four Screws
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Location: The sender for rotation rate -G202- -1- and the sensor for transverse acceleration -G200- -2- are
secured to a bearing bracket on the steering column -3-.

Fig. 74: Locating Sender For Rotation Rate -G202- (-1-) And Sensor For Transverse Acceleration -
G200-

Courtesy of VOLKSWAGEN OF AMERICA, INC.

a. Steering column

z

Pull connector -arrow- off sender for rotation rate -G202- and pull connector off sensor for transverse
acceleration -G200-.

z

Remove bolt -1- and take out sender for rotation rate -G202- and sensor for transverse acceleration -
G200-.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 75: Removing Bolt And Take Out Sender For Rotation Rate -G202- And Sensor For
Transverse Acceleration -G200-

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing sender for rotation rate -G202-

z

Remove nuts -a- from sender for rotation rate - G202- -1-.

z

Take out sender for rotation rate -G202-.

Fig. 76: Removing Nuts From Sender For Rotation Rate - G202-
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing sensor for transverse acceleration -G200-

z

Pry retainer -1- off sensor for transverse acceleration -G200- -2- using a screwdriver.

z

Take out sensor for transverse acceleration -G200-.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle
