Volkswagen New Beetle. Manual - part 678





Fig. 77: Prying Retainer Off Sensor For Transverse Acceleration -G200- Using A Screwdriver
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Installing sender for rotation rate -G202-

z

Insert sender for rotation rate -G202- and align so that it is straight.

z

Install nuts -a- and tighten so that the sender for rotation rate -G202- -1- is secure.

Fig. 78: Installing Nuts And Tightening So Sender For Rotation Rate -G202- Is Secure
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing sensor for transverse acceleration -G200-.

z

Insert lateral acceleration sensor -G200- in bracket.

z

Installation position: The angled section -arrow- of the lateral acceleration sensor -G200- -1- must face
toward the retainer -2-.

z

Slide retainer -2- over the lateral acceleration sensor -G200- -1- until it locks in position.

Further installation in reverse order

z

Enter radio code.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 79: Identifying Angled Section Of Lateral Acceleration Sensor -G200-
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Tightening torques:

Sender for rotation rate -G202- to bracket : 9 N.m : (79 in. lb)

Hex bolt to steering column mounting bracket : 20 N.m : (15 ft. bracket lb)

ESP-SENSOR UNIT -G419-, VEHICLES FROM M.Y. 12.01, REMOVING AND INSTALLING

The sensor for transverse acceleration -G200-, and the sender for rotation rate -G202- are assembled together in
one housing on a new bracket, at the same place in the vehicle.

z

The ESP-sensor unit -G419- -1- is fixed with a bracket on the steering column bearing bracket -a-.

When the ESP-sensor unit -G419- is replaced, a zero compensation of the sensor for transverse acceleration -
G200-, and the sender for rotation rate -G202-, must be performed.

Fig. 80: Locating ESP-Sensor Unit -G419-



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Pull off connector -arrow- from ESP-sensor unit -G419-

z

Unscrew bolt -1- and remove ESP-sensor unit -G419-

Fig. 81: Pulling Off Connector From ESP-Sensor Unit -G419-
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unscrew nuts -a- from the ESP-sensor unit -G419-

z

Remove ESP-sensor unit -G419-

Fig. 82: Identifying Nuts From ESP-Sensor Unit -G419-
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Further installation in reverse order



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Tightening torques:

ESP-sensor unit -G419- to bracket : 9 N.m : (79.7 in. lb)

Hex bolt to steering column mounting bracket : 20 N.m : (15 ft. lb)

z

Enter radio code.

z

Perform basic settings of sensor for transverse acceleration -G200- and sender for rotation rate -G202-.

See INITIATING BASIC SETTING .

STEERING ANGLE SENSOR -G85-, REMOVING AND INSTALLING

Removing

z

Removing airbag module and steering wheel.

See DRIVER-SIDE AIR BAG MODULE and STEERING WHEEL .

z

Turn wheels to straight ahead position.

z

Take out covering in footwell.

z

Remove bolts -1-.

z

Take off handle for height and reach adjustment -5-.

Fig. 83: Locating Handle For Handle For Height And Reach Adjustment & Lower Steering
Column Switch Trim

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unscrew bolts -2-, -3- and -4-.

z

Take off lower steering column switch trim.

z

Remove upper steering column switch trim -1-.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle
