1. ABS speed sensor

z

Before inserting sensor, clean mounting hole inner surface and coat with lubricant G 000 650

2. Hex socket head bolt, 8 N.m (71 in lb)

3. Stub axle

4. Splash plate

5. Hex bolt, 60 N.m (44 ft. lb)

z

With dished spring

6. Phillips-head screw

7. Brake disc

8. 8-Cap

z

Pressing off and driving in

See WHEEL BEARING

9. Self-locking 12-point nut, 175 N.m (129 ft. lb)

z

Replace each time after removing

10. Wheel hub with wheel bearing and rotor

z

Only replace complete

z

Removing and installing

See WHEEL BEARING

11. Axle beam

Fig. 64: Identifying ABS System Components On Rear Axle
Courtesy of VOLKSWAGEN OF AMERICA, INC.

SPEED SENSOR ON REAR AXLE, REMOVING AND INSTALLING

Removing

z

Raise vehicle.

z

Disconnect speed sensor and speed sensor wiring connector -1-.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



z

Remove bolt -2- from stub axle.

z

Disconnect ABS speed sensor out of stub axle.

Fig. 65: Disconnecting ABS Speed Sensor Out Of Stub Axle
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Before inserting speed sensor, clean hole inner surface and coat speed sensor with solid lubricant paste G
000 650.

z

Insert speed sensor into hole in stub axle and tighten bolt to 8 N.m (71 in. lb)

z

Connect speed sensor to speed sensor wiring.

Checking or removing and installing rotor on rear axle

z

Raise vehicle.

z

Remove wheel.

z

Remove bolt for ABS speed sensor from stub axle.

z

Disconnect ABS speed sensor out of stub axle.

z

Check rotor is not damaged or dirty.

z

If rotor is damaged, remove wheel hub with rotor and replace.

See FRONT & REAR BRAKE ROTOR and WHEEL BEARING

REAR SPEED SENSOR WIRING, REMOVING AND INSTALLING

Special tools and equipment

z

VAS 1978 Wiring harness repair kit

Removing:



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



z

Obtain radio code on vehicles with coded radio.

z

Disconnect battery.

z

Separate speed sensor wiring/speed sensor connection.

z

Remove rear side panel trim.

See SIDE PANEL TRIM, REMOVING AND INSTALLING .

z

Disconnect speed sensor wiring -arrow- with wire strippers from VAS 1978 and remove faulty wiring.

Fig. 66: Disconnecting Speed Sensor Wiring With Wire Strippers From VAS 1978
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Strip 15 mm (5/8 in.) of insulation from end of wire with wire stripper and fold half of stripped wire back.

z

Guide in new speed sensor wiring.

z

Connect speed sensor to speed sensor wiring.

z

Clip in speed sensor wiring -arrow-.

Make sure the wiring is not twisted when installing the speed sensor wiring in the wheel housing.

z

Cut 2-pin connector off new speed sensor wiring with wire stripper pliers.

z

Strip 15 mm (5/8 in.) of insulation from end of wire with wire strippers and bend back half.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 67: Striping 15 Mm Of Insulation From End Of Wire With Wire Stripper
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect speed sensor wiring with help of suitable crimp connector from wiring harness repair kit VAS
1978.

Fig. 68: Cliping In Speed Sensor Wiring
Courtesy of VOLKSWAGEN OF AMERICA, INC.

ESP SYSTEM COMPONENTS, REMOVING AND INSTALLING

SENDER FOR ROTATION RATE -G202- AND SENSOR FOR TRANSVERSE ACCELERATION -
G200-, REMOVING AND INSTALLING

Removing

NOTE:

The removal and installation sequence for the sender for rotation rate -G202-
and the sensor for transverse acceleration -G200- is identical except for the
mounting bracket for each component.
