Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect intake hose -1- and connector -2- off mass air flow sensor.

z

Remove bolts -3-, -4- and -5-.

z

Remove air cleaner complete.

Fig. 55: Disconnecting Intake Hose And Connector Off Mass Air Flow Sensor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Release control module connector (arrow -1-) and pull off (arrow -2-).

Fig. 56: Releasing Control Module Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Release multi-pin connector cover cap with a screwdriver and remove.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 57: Releasing Multi-Pin Connector Cover Cap With A Screwdriver
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Release secondary locking device (violet) in direction of arrow with a little screwdriver.

Fig. 58: Releasing Secondary Locking Device In Direction Of Arrow With A Little Screwdriver
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Fig. 59: Identifying Connector T25 Wiring Harness Terminal
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Contact assignment of connector T25 wiring harness/ ABS Control Module (w/EDL) -J104-

Contact Connected to component

19 + 20 Right Front ABS Wheel Speed Sensor -G45-

1+2 Left Front ABS Wheel Speed Sensor -G47-

z

Push out relevant contacts with an ejection tool from wiring harness repair kit VAS 1978.

z

Separate connector from speed sensor wiring and speed sensor.

Fig. 60: Pushing Out Relevant Contacts With An Ejection Tool From Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

In addition, disconnect connection -1- on vehicles with a brake pad wear indicator.

Fig. 61: Disconnecting Connection On Vehicles With A Brake Pad Wear Indicator
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unclip the wiring from retainer -2-.

z

Remove the faulty speed sensor wiring.

Installing



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



z

Route the new speed sensor wiring.

z

Connect speed sensor to speed sensor wiring.

z

Clip in speed sensor wiring -arrows-.

Make sure the wiring is not twisted when installing the speed sensor wiring in the wheel housing.

z

Insert brake wear indicator connector into retainer on suspension strut.

z

Guide contacts into connector housing.

Fig. 62: Cliping In Speed Sensor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Push individual wiring seals in onto stop with an insertion tool from VAS 1978.

Fig. 63: Pushing Individual Wiring Seals In Onto Stop With An Insertion Tool From VAS 1978
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Secure contacts with secondary locking device and install multi-pin connector cover cap.

ABS SYSTEM COMPONENTS ON REAR AXLE, REMOVING AND INSTALLING

NOTE:

The following list refers to items in .Fig. 64



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle
