Volkswagen New Beetle. Manual - part 674





See WHEEL BEARING (WHEEL BEARING HOUSING INSTALLED

10. Circlip



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 51: Identifying ABS System Components On Front Axle - ABS MARK 60
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Removing and installing speed sensor on front axle

Removing

z

Raise vehicle.

z

Disconnect speed sensor and speed sensor wiring connector -1-.

z

Remove bolt -2- from wheel bearing housing.

z

Disconnect ABS speed sensor from wheel bearing housing.

Installing

z

Before inserting speed sensor, clean hole inner surface and coat speed sensor with solid lubricant G 000
650.

z

Insert speed sensor into hole in wheel bearing housing and tighten bolt to 8 N.m (71 in. lb).

z

Connect speed sensor to speed sensor wiring.

z

Turn wheels fully to left and right lock and check clearance of speed sensor wiring.

Fig. 52: Disconnecting Speed Sensor And Speed Sensor Wiring Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking or removing and installing rotor on front axle

z

Raise vehicle.

z

Remove wheel.

z

Rotate brake disc and check rotor is not damaged or dirty.

z

If rotor is damaged, remove wheel hub with rotor and replace.

See WHEEL BEARING (WHEEL BEARING HOUSING INSTALLED

Checking rotor lateral run-out

z

Raise vehicle.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



z

Remove wheel.

z

Turn wheel hub and check gap -dimension a- between rotor and speed sensor is even.

Dimension a = 0.3 mm (0.0118 in.)

z

If rotor is damaged, remove wheel hub with rotor and replace.

See WHEEL BEARING (WHEEL BEARING HOUSING INSTALLED

Fig. 53: Check Gap Between Rotor And Speed Sensor Is Even
Courtesy of VOLKSWAGEN OF AMERICA, INC.

FRONT SPEED SENSOR WIRING, REMOVING AND INSTALLING

Special tools and equipment

z

VAS 1978 Wiring harness repair kit

Removing:

z

Obtain radio code on vehicles with coded radio.

z

Disconnect battery.

Fig. 54: Identifying VAS 1978 Wiring Harness Repair Kit



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle
