Fig. 17: Removing Cover Caps (Convertible)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Raise or lower door window -4- until the clamps are accessible in the assembly openings -1-.

z

Loosen bolts/screws -2- and press clamps apart. See Fig. 17 .

z

Remove bolt/screw -3-.

NOTE:

If work sequence cannot be carried out because there is a malfunction
with electric window motor, remove motor to slide window down.
Assembly carrier must be removed for this.



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle



z

Lift door window -1- and pull out toward rear over the slot at door lock.

Fig. 18: Lifting Door Window (Convertible)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Slide door window -1- carefully into door slot so that the threaded plate -2- does not fall off.



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle



Fig. 19: Installing Door Window (Convertible)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Install in reverse order of removal.

DOOR WINDOW, ADJUSTING (CONVERTIBLE)

z

Door adjustment to body and convertible top adjustment to windshield frame are OK.

Adjusting door window to front window guide.

NOTE:

z

Adjust door window, see DOOR WINDOW, ADJUSTING
(CONVERTIBLE) .

z

Apply locking compound to bolts/screws -2- and -3- before
tightening.



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle



z

Door window -4- bolted lightly to window regulator.

z

Raise or lower door window until the clamps are accessible in the assembly openings -1-.

z

Loosen clamps -2- and -3- and press door window into front window guide -arrow-.

z

Tighten clamps, torque setting: 10 N.m.

Fig. 20: Adjusting Door Window (Convertible)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

ASSEMBLY CARRIER, REMOVING AND INSTALLING (CONVERTIBLE)

Door lock and loudspeaker are secured to assembly carrier.

NOTE:

z

Apply locking compound to bolts/screws -2- and -3- before
tightening.



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle
