Door lock can only be removed in conjunction with assembly carrier.

Removing

z

Remove front door trim.

See FRONT DOOR TRIM (CONVERTIBLE), REMOVING AND INSTALLING .

z

Remove lock cylinder housing. See LOCK CYLINDER HOUSING, REMOVING .

z

Unclip clip -1- from door handle.

Fig. 21: Removing Clip From Door Handle
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unscrew bolts/screws -1-. Torque setting: 20 N.m.



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle



Fig. 22: Removing Door Lock Bolts/Screws
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unclip wiring harness and disconnect connections -arrows-.



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle



Fig. 23: Locating Wiring Harness And Electrical Connections (Convertible)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove bolts/screws -1-, -3- and nut -2-. Pull top of assembly carrier off door, lift and take out of door
toward hinges.

z

Turn mounting plate around and disconnect connector from door lock.



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle



Fig. 24: Turning Mounting Plate Around And Disconnecting Connector From Door Lock
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull wiring harness through assembly carrier.

z

Unclip clips for electrical wiring on back of mounting plate.

Installing

Install in reverse order of removal.

FRONT WINDOW REGULATOR, REMOVING AND INSTALLING (CONVERTIBLE)

NOTE:

The following list refers to items in Fig. 25 .
