Volkswagen New Beetle. Manual - part 537





Fig. 42: Hooking Convertible Top Lining Into Convertible Top Fabric Retaining Frame
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Start at the center when doing this.

z

Secure water guide -1- with insert beading -2-.

Fig. 43: Securing Water Guide With Insert Beading
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Secure side tensioning belt -1- to convertible top frame with a pop rivet.

z

Open convertible top to half open position.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 44: Securing Side Tensioning Belt To Convertible Top Frame With Pop Rivet
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Insert beading into C-pillar channel in direction of -arrow-.

Fig. 45: Inserting Beading Into C-Pillar Channel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Hook hooking beading into channel on front of roof leading edge -arrow-.

NOTE:

Beading must close flush with upper edge of C-pillar.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 46: Installing Hooking Beading Into Channel On Front Of Roof Leading Edge
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press convertible top fabric clamping beading into side of roof leading edge clamping channel -arrow-.

Fig. 47: Pressing Convertible Top Fabric Clamping Beading Into Side Of Roof Leading Edge
Clamping Channel

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install convertible top fabric securing bolt/screw -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 48: Installing Convertible Top Fabric Securing Bolt/Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install roof frame front seal -arrow A-.

z

Install C-pillar seal -arrow B-.

Fig. 49: Installing Roof Frame Front Seal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install roof leading edge trim, see CONVERTIBLE TOP FRONT LATCH, ASSEMBLY
OVERVIEW
 .

z

Install side panel trim

See SIDE PANEL TRIM, REMOVING AND INSTALLING .

z

Install head restraint trim.

See BACKREST (CONVERTIBLE), REMOVING AND INSTALLING .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle
