Volkswagen New Beetle. Manual - part 535





Fig. 26: Cutting Through Staple
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Release padding material bonding on C-pillar -arrow-.

Fig. 27: Removing Padding Material Bonding On C-Pillar
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove bolt/screw -1- for convertible top cover tensioning cable.

z

Pull tensioning cable out if replacing convertible top cover.

z

Remove screw -2- securing elastic strap to convertible roof frame.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 28: Removing Bolt/Screw For Convertible Top Cover Tensioning Cable
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull convertible top fabric -1- out of convertible top retaining rail -2- to side in direction of -arrow-
(second mechanic required).

Fig. 29: Pulling Convertible Top Fabric Out Of Convertible Top Retaining Rail
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Slide convertible top fabric into convertible top retaining rail from side (second mechanic required).

Use lubricant when pulling in (e.g. silicone lubricant spray D 007 000 A2).

z

Align mark on rear of padding material with mark on convertible top fabric.

WARNING:

For security reasons, hold tensioning cable while removing screw



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 30: Aligning Mark On Rear Of Padding Material With Mark On Convertible Top Fabric
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Close zip fastener using Closing Pliers VAS 6138.

Fig. 31: Closing Zip Fastener
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Secure ends of zip fastener with Staple Pliers VAS 6148.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 32: Securing Ends Of Zip Fastener
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Make sure that the staple is closed correctly.

z

Align mark on center of padding material with mark on convertible top fabric and close zip fastener.

z

Align mark on front of padding material with mark on convertible top fabric and close zip fastener.

z

If replacing convertible top fabric cover, pull tensioning cable into side of convertible top fabric with aid
of pilot wire.

Fig. 33: Pulling Tensioning Cable Into Side Of Convertible Top Fabric With Aid Of Pilot Wire
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Secure rear of cable with bolt/screw.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle
