Volkswagen New Beetle. Manual - part 536





Fig. 34: Securing Rear Of Cable With Bolt/Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Hook ball into front of roof frame.

Fig. 35: Hooking Ball Into Front Of Roof Frame
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Stick padding material onto C-pillar -arrow-using double-sided adhesive tape.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 36: Sticking Padding Material Onto C-Pillar
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check sealing cord -1- on convertible top retaining frame, replace if necessary.

Fig. 37: Identifying Sealing Cord On Convertible Top Retaining Frame
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove Assembly Bracket V.A.G 1887 from convertible top fabric retaining frame and body.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 38: Removing Assembly Bracket V.A.G 1887 From Convertible Top Fabric Retaining Frame
And Body

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Position convertible top fabric retaining frame and tighten nut -4- (10 N.m) first.

z

Tighten bolts/screws -3- (10 N.m) working from the center outward.

Fig. 39: Positioning Convertible Top Fabric Retaining Frame
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press hinge -6- into ball socket -2- and secure with securing clip -3-.

z

Secure retaining clip -5- with a pop rivet -4-.

z

Reconnect electrical connection -1- for rear window defroster.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 40: Pressing Hinge Into Ball Socket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press beading into insert channel of rear window -arrow-.

Fig. 41: Pressing Beading Into Insert Channel Of Rear Window
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Hook convertible top lining -2- into convertible top fabric retaining frame -1- in opposite direction of -
arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle
