Volkswagen New Beetle. Manual - part 534





Fig. 18: Removing Beading From C-Pillar Channel
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Close convertible top.

z

Fold convertible top fabric cover rearward.

z

Cut through staple using side cutting pliers and open front of zip fastener.

Fig. 19: Cutting Through Staple
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove insert beading -2- from water guide -1-.

Fig. 20: Removing Insert Beading From Water Guide
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove convertible top lining -2- out of convertible top fabric retaining frame -1- in direction of -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 21: Removing Convertible Top Lining Out Of Convertible Top Fabric Retaining Frame
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove beading -2- out of rear window insert channel -1- -arrow-.

Fig. 22: Removing Beading Out Of Rear Window Insert Channel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect electrical connection -1- for rear window defroster -Z1-.

z

Drill pop rivet -4- carefully out of retaining clip -5-.

z

Pull securing clip -3- out of ball socket -2-.

z

Pull hinge -6- out of ball socket.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 23: Disconnecting Electrical Connection For Rear Window Defroster
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove bolts/screws -3- (10 N.m) and nuts -4-(10 N.m) from body -1-.

z

Press convertible top fabric retaining frame -2- off body -1-.

Fig. 24: Removing Convertible Top Fabric Retaining Frame From Body
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Sealing band between the convertible top fabric retaining frame and body can lead to convertible top
retaining frame bonding slightly.

z

Secure convertible top fabric retaining frame with Assembly Bracket V.A.G 1887 to body.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 25: Securing Convertible Top Fabric Retaining Frame With Assembly Bracket V.A.G 1887 To
Body

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Cut through staple using side cutting pliers and open center and rear of zip fastener.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle
