Volkswagen New Beetle. Manual - part 532





Fig. 5: Removing Convertible Top Frame From Body
Courtesy of VOLKSWAGEN OF AMERICA, INC.

See LUGGAGE COMPARTMENT TRIM (CONVERTIBLE), REMOVING AND INSTALLING .

z

Disconnect connection -1- on left and right-hand side of rear window.

Fig. 6: Disconnecting Connection On Left And Right-Hand Side Of Rear Window
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Guide wiring for heated rear window into interior and unclip from side panel.

z

Open convertible top completely.

z

Unclip Convertible Top Position Switch -F171- -3- for convertible top position from hydraulic cylinder
(right-hand side only).

z

Pry securing clip -4- out of piston rod -1-.

z

Pry piston rod -1- off ball head -2- using a screwdriver.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 7: Prying Piston Rod Off Ball Head
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove bolts/screws -2-.

z

Close convertible top manually but do not lock.

z

Remove bolt/screw -4-.

Fig. 8: Removing Convertible Top Bolt/Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lift convertible top at main mounting approx. 45° and take forward out of the convertible top box
(second mechanic required).

Installing

NOTE:

Never loosen the securing bolts/screws -1- and -3- of the base plate
otherwise the default settings for the convertible top will be lost.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



z

Check sealing band -1- on convertible top frame, replace if necessary.

z

Place convertible top in convertible top box (second mechanic required).

z

Install bolts/screws -2- and -4- and tighten to 50 N.m.

Fig. 9: Identifying Sealing Band On Convertible Top Frame
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Position convertible top frame centrally and tighten nut -4- (10 N.m).

z

Tighten bolts/screws -3- (10 N.m) working from the center outward.

Fig. 10: Positioning Convertible Top Frame Centrally
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Install in reverse order of removal.

NOTE:

make sure that the convertible top fabric retaining frame is positioned at the
same height.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



CONVERTIBLE TOP FABRIC COVER, REMOVING AND INSTALLING

z

Remove side trim panel.

See SIDE PANEL TRIM, REMOVING AND INSTALLING .

z

Remove head restraint cover.

See BACKREST (CONVERTIBLE), REMOVING AND INSTALLING .

Removing

z

Open convertible top half way.

z

Observe security rules, see CONVERTIBLE TOP .

z

Remove roof leading edge trim, see CONVERTIBLE TOP FRONT LATCH, ASSEMBLY
OVERVIEW


z

Pull roof frame front seal off roof frame -arrow-.

Fig. 11: Pulling Roof Frame Front Seal From Roof Frame
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

z

On models with an electro/hydraulic convertible top the motors for the rod
flaps must remain connected to the wiring harness so that the convertible
top may be moved hydraulically.

z

Position side trim panels in the vehicle so that the rod flats can move
freely.

z

The servo motors may be disconnected from the flap motor.

z

Protect the vehicle against possible paintwork damage with suitable
protective covers and textile reinforced adhesive tape.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle
