Volkswagen New Beetle. Manual - part 533





z

Remove convertible top fabric securing bolt/screw -arrow-.

Fig. 12: Removing Convertible Top Fabric Securing Bolt/Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull convertible top fabric clamping beading out to side from roof leading edge clamping channel -arrow-

Fig. 13: Pulling Convertible Top Fabric Clamping Beading Out To Side From Roof Leading Edge
Clamping Channel

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull hooking beading out of front of roof leading edge -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 14: Pulling Hooking Beading Out Of Front Of Roof Leading Edge
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unhook cable with ball -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 15: Removing Cable Hook With Ball
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Drill out pop rivet -arrow- from interior for side tensioning belt -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 16: Drilling Out Pop Rivet From Interior For Side Tensioning Belt
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove C-pillar roof frame seal in direction of -arrow-.

Fig. 17: Removing C-Pillar Roof Frame Seal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove beading from C-pillar channel in direction of -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle
