1998-2004 ACCESSORIES & EQUIPMENT

Convertible Top - New Beetle

CONVERTIBLE TOP

SECURITY RULES

Open convertible top by activating the open/close button

Security instructions when dealing with the electrical convertible top

TOOLS

z

VAS 6138 Closing Pliers.

z

VAS 6148 Staple Pliers.

z

VAS 6148/1 Staples.

z

VAS 5072 Pop Rivet Pliers.

z

V.A.G 1887 Fitting Brackets.

NOTE:

z

Observe safety instructions for electrical convertible top.

z

Before opening or closing convertible top, observe that there is enough
room above convertible top to operate it.

WARNING:

z

For security reasons convertible top must only be opened or closed
when vehicle is parked.

z

If opening or closing process is interrupted, convertible top may
spring and thus be lowered.

z

Never drive the vehicle if convertible top is not opened or closed
completely.

z

Do not attempt to close convertible top when rollover bar is
activated.

WARNING:

z

When opening or closing convertible top, observe that nobody gets
injured by convertible top, convertible rods or moving covers at rear
side windows.

z

Do not open or close convertible top when vehicle is over a lifting
platform, over a trolley jack, or over one side on curb.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 1: Identifying Special Tools
Courtesy of VOLKSWAGEN OF AMERICA, INC.

CONVERTIBLE TOP, ASSEMBLY OVERVIEW

1. Convertible top frame

z

Removing convertible top, see CONVERTIBLE TOP, REMOVING AND INSTALLING .

2. Convertible top fabric cover

z

Replacing, see CONVERTIBLE TOP FABRIC COVER, REMOVING AND INSTALLING .

z

Rear window is part of convertible top cover.

3. Padding material

z

Replacing, see PADDING MATERIAL, REMOVING AND INSTALLING .

4. Nut

z

10 N.m.

5. Bolt/screw

z

Qty. 12.

z

10 N.m.

6. Sealing cord

7. Convertible top lining

z

Replacing, see CONVERTIBLE TOP LINING, REMOVING AND INSTALLING

8. Bolt/screw

NOTE:

The following list refers to items in Fig. 2 .

NOTE:

Rear window is part of convertible top cover (not serviced separately).
Entire convertible top fabric assembly must be replaced if rear window is
damaged.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



z

50 N.m.

9. Convertible top front latch

z

Removing, see CONVERTIBLE TOP FRONT LATCH, ASSEMBLY OVERVIEW

10. Front retaining latch

z

Removing, see CONVERTIBLE TOP FRONT LATCH, ASSEMBLY OVERVIEW

Fig. 2: Exploded View Of Convertible Top
Courtesy of VOLKSWAGEN OF AMERICA, INC.

CONVERTIBLE TOP, REMOVING AND INSTALLING

Removing

z

Remove side trim panel.

See SIDE PANEL TRIM, REMOVING AND INSTALLING .

z

Remove head restraint cover

See BACKREST (CONVERTIBLE), REMOVING AND INSTALLING .

NOTE:

z

On models with an electro/hydraulic convertible top the motors for the rod
flaps must remain connected to the wiring harness so that the convertible
top may be moved hydraulically.

z

Position side trim panels in the vehicle so that the rod flaps can move
freely.

z

The servo motors may be disconnected from the flap motor.

z

Protect the vehicle against possible paintwork damage with suitable
protective covers and textile reinforced adhesive tape.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



z

Open convertible top latch to remove pressure from convertible top.

z

Remove insert beading -2- from water guide -1-.

Fig. 3: Removing Insert Beading From Water Guide
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove convertible top lining -2- from convertible top fabric cover retaining frame -1- in direction of -
arrow-.

Fig. 4: Removing Convertible Top Lining From Convertible Top Fabric Cover Retaining Frame
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove bolts/screws -3- (10 N.m) and nuts -4- (10 N.m) from body -1-.

z

Press convertible top frame -2- off body -1-.

Sealing band between convertible top fabric retaining frame and body can lead to convertible top
retaining frame bonding slightly.

z

Remove luggage compartment side trim on left and right.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle
