Volkswagen New Beetle. Manual - part 529





Fig. 44: Identifying Left Backrest Locking Device (Two Piece) Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

LEFT BACKREST LOCKING DEVICE (TWO PIECE), REMOVING AND INSTALLING

Removing

z

Remove backrest, see SEAT BACKREST (TWO PIECE), REMOVING AND INSTALLING .

z

Remove padding.

z

Press connecting rod -1- ball joint off locking hooks -2- with a screwdriver -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



Fig. 45: Pressing Connecting Rod Ball Joint Off Locking Hooks
Courtesy of VOLKSWAGEN OF AMERICA, INC.


z

Release circlip -1- from pin -2-.

Fig. 46: Removing Circlip From Pin
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Release spring -3- from backrest -4- with a screwdriver.

z

Pull pin -2- out of backrest -4-, when doing this hold spring -3- with a pair of pliers and pull out.

Fig. 47: Pulling Pin Out Of Backrest
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unclip operating rod -1- in clip -2- by swinging to right -arrow- and pull out of clip.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



Fig. 48: Removing Operating Rod Out Of Clip
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Take clip -2- off release rod -3-.

z

Disassemble release rods -1- and -2- and clips -4- from rear panel -3-.

Fig. 49: Disassembling Release Rods And Clips From Rear Panel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

NOTE:

z

The release rods -1- and -2- must be taken together upward together
out of backrest or inserted together when installing.

z

The clips -4- can be disassembled from the rear panel, when the
spreader pin is pushed out of the clip. (Remove spreader pin from
rear panel ready for reinstallation).



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



z

Pin -2-, spring -3- and locking hooks -4- must be inserted together.

Fig. 50: Inserting Locking Hooks
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Engage circlip -1- in pin -2-.

z

Tension spring -3-.

z

Perform a functional check after assembling is completed, adjust locking hooks if necessary.

Adjusting locking hooks

z

If part of original equipment, loosen nut -3- and press connecting rod ball joint -1- off locking hooks -2- -
arrow- with a screwdriver

z

Turn ball joint -1- on connecting rod so that the effective length of the connecting rod is increased or
decreased as applicable.

Fig. 51: Adjusting Locking Hooks - Left Backrest Locking Device (Two Piece)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle
