Volkswagen New Beetle. Manual - part 527





Fig. 32: Locating Button Housing & Release Rods
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disassemble release rods -2- and clips -4- from rear panel -3-.

Installing

Install in reverse order of removal.

z

Pin -2-, spring -3- and locking hooks -4- must be inserted together.

Fig. 33: Inserting Locking Hooks
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Engage circlip -1- in pin -2-.

NOTE:

The clips -4- can be disassembled from the rear panel, when the spreader
pin is pushed out of the clip. (Remove spreader pin from rear panel ready
for reinstallation).



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



z

Tension spring -3-.

z

Perform a functional check after assembling is completed, adjust left and right-hand locking hooks if
necessary.

Adjusting locking hooks

z

If part of original equipment, loosen nut -3- and press connecting rod ball joint -1- off locking hooks -2- -
arrow- with a screwdriver

Fig. 34: Adjusting Locking Hooks
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn ball joint -1- on connecting rod so that the effective length of the connecting rod is increased or
decreased as applicable.

REAR SEAT BENCH (TWO PIECE), REMOVING AND INSTALLING

Removing

z

Lift seat bench and pull forward.

z

Press rods -2- out of retainers -3-.

Fig. 35: Removing Rear Seat Bench (Two Piece)



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Guide rods -2- into retainers -3-, fold seat bench -1- downward to rear and push front edge downward.

SEAT BACKREST (TWO PIECE), REMOVING AND INSTALLING

Removing

z

Fold seat backrest -1- forward.

z

Press locking hooks -2- back -arrow A- with a screwdriver.

z

Lift backrest -1- up out of mounting -3- and pull off center anchorage -4- -arrow B-.

Fig. 36: Removing Seat Backrest (Two Piece)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Guide backrest -1- onto anchorage -4- and push outer side downward into mounting -3-.

RIGHT BACKREST LOCKING DEVICE (TWO PIECE), ASSEMBLY OVERVIEW

1. Release rod

NOTE:

The illustration depicts the left seat bench only. Removing the right seat bench
is identical.

NOTE:

The illustration depicts the left seat backrest only. Removing the right seat
backrest is identical.

NOTE:

The following list refers to items in Fig. 37 .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



2. Clip

3. Padding

4. Cover

5. Padding wire

6. Button

7. Pin

8. Rear panel

9. Locking hook

10. Connecting rod

Fig. 37: Identifying Right Backrest Locking Device (Two Piece)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

RIGHT BACKREST LOCKING DEVICE (TWO PIECE), REMOVING AND INSTALLING

Removing

z

Remove backrest, see SEAT BACKREST (TWO PIECE), REMOVING AND INSTALLING .

z

Remove padding.

z

Press connecting rod -1- ball joint off locking hooks -2- with a screwdriver -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle
