Volkswagen New Beetle. Manual - part 525

Fig. 19: Removing Cable Guide On Seat Frame
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

z

Push locking device -1- into bracket onto limit stop and adjust cut-out -arrow- to correct position.

z

Press clip -2- on securely

Fig. 20: Pushing Locking Device Into Bracket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

REMOVING AND INSTALLING LUMBAR SUPPORT FRAME FROM 05.03 ON

Removing

z

Remove seat. See FRONT SEATS, REMOVING AND INSTALLING .

z

Remove backrest. See FRONT SEAT BACKREST, ASSEMBLY OVERVIEW .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



z

Remove backrest cover.

z

Remove backrest padding.

Fig. 21: Identifying Lumbar Support Frame - From 05.031 On
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove bolts -2- and remove adjustment device -3- from the seat backrest -1-.

z

Drill out pop rivet -4-.

z

Unclip lumbar support frame -5- from the seat backrest -arrows-.

Installing

Install in reverse order.

REMOVING AND INSTALLING BACKREST RELEASE OPERATING DEVICE CABLE FROM
05.03 ON

Removing

z

Remove seat. See FRONT SEATS, REMOVING AND INSTALLING .

z

Remove backrest. See FRONT SEAT BACKREST, ASSEMBLY OVERVIEW .

z

Remove backrest cover.

z

Remove backrest padding.

z

Loosen cable -5-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



Fig. 22: Locating Backrest Release Operating Device Cable - From 05.03 On
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unhook cable hook -4- and remove cable -2- from guide -3-.

z

Rotate the cable ball joint -7- 90° and remove from release lever -8-.

z

Unclip clip -6- and remove cable -2- from backrest frame -1-.

Installing

Install in reverse order.

REAR SEATS

REAR SEAT BENCH (ONE PIECE), REMOVING AND INSTALLING

Removing

z

Lift seat bench and pull forward.

z

Press rods -2- out of retainers -3-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



Fig. 23: Identifying Rear Seat Bench (One Piece)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Guide rods -2- into retainers -3-, fold seat bench -1- downward to rear and push front edge downward.

BACKREST (ONE PIECE), REMOVING AND INSTALLING

Removing

z

Remove bolts/screws -1- from retaining supports -2- on the center support -3- on back of backrest.

Fig. 24: Removing Retaining Supports On Center Support On Back Of Backrest
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Fold seat bench forward. See REAR SEATS .

z

Fold backrest down.

z

Press retaining hooks -1- on left and right-hand sides back with a screwdriver and pull backrest -2-
