Volkswagen New Beetle. Manual - part 538





PADDING MATERIAL, REMOVING AND INSTALLING

Removing

z

Remove convertible top cover. See CONVERTIBLE TOP FABRIC COVER, REMOVING AND
INSTALLING
 .

z

Remove C-pillar padding securing bolts/screws from convertible top fabric retaining frame and pull
clamping beading out -arrow-.

Fig. 50: Removing C-Pillar Padding From Convertible Top Fabric Retaining Frame
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Guide wiring for heated rear window and hinge through padding material.

Fig. 51: Identifying Wiring For Heated Rear Window
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove securing bolt on roof frame for rubber cable.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



z

Pull rubber cable out of loop on convertible top lining.

Fig. 52: Removing Securing Bolt On Roof Frame For Rubber Cable
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull beading out of roof leading edge.

Fig. 53: Pulling Beading Out Of Roof Leading Edge
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Open convertible top to half open position.

z

Remove convertible top lining as far as rear bracing hoop, see CONVERTIBLE TOP LINING,
REMOVING AND INSTALLING
 .

z

Remove securing bolts/screws -1- for top padding tensioning belt from sides of bracing hoops 2 and 4.

WARNING:

For security reasons, hold tension on elastic strap while removing
screw



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 54: Removing Top Padding Tensioning Belt Securing Bolts/Screws
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove guiding rubber cable securing bolt/screw from bracing hoop 3 to tensioning cable convertible top
frame -arrow-.

Fig. 55: Removing Guiding Rubber Cable Securing Bolt/Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove guiding rubber cable securing bolt/screw from bracing hoop 2 -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle



Fig. 56: Removing Guiding Rubber Cable Securing Bolt/Screw From Bracing Hoop
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Fold padding material to rear.

z

Pull padding material out of bracing hoop -arrow- to side.

Fig. 57: Pulling Padding Material Out Of Bracing Hoop To Side
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Pull padding material into bracing hoops 2, 4 and the rear bracing hoop.

Use lubricant when pulling in (e.g. silicone lubricant spray D 007 000 A2).

WARNING:

For security reasons, hold tension on elastic strap while removing
screw



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Convertible Top - New Beetle
