Volkswagen New Beetle. Manual - part 521





1. Sill panel trim strip

2. Clip

z

Qty. 5

3. Door inner seal

4. Carpet

Fig. 62: Identifying Sill Panel Trim
Courtesy of VOLKSWAGEN OF AMERICA, INC.

SILL PANEL TRIM STRIP, REMOVING AND INSTALLING

Removing

z

Remove A-pillar lower trim. See A-PILLAR LOWER TRIM, REMOVING AND INSTALLING .

z

Remove side panel trim. See SIDE PANEL TRIM, ASSEMBLY OVERVIEW . For convertible, see
SIDE PANEL TRIM, ASSEMBLY OVERVIEW .

z

Unclip sill panel trim strip -1- upward.

Installing

Install in reverse order of removal.

outs at the ends of the sill panel.

NOTE:

The following list refers to items in Fig. 62 .

NOTE:

z

Check clips - 2 - before installing sill panel trim strip and replace as
necessary.

z

Make sure seal -3- is seated correctly after installing sill panel trim strip.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



SILL PANEL TRIM STRIP (CONVERTIBLE), ASSEMBLY OVERVIEW

1. Sill panel trim strip

2. Clip

z

Qty. 6

3. Release lever

z

Removing and installing. See RELEASE LEVER, REMOVING AND INSTALLING .

4. Cover

5. Bolt/screw

6. Spreader nut

7. Carpet

8. Door inner seal

Fig. 63: Removing Sill Panel Trim Strip
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

The sill panel is partially covered at the rear by the side panel trim. Retaining
clips for these panels seat in the cut-outs at the ends of the sill panel.

NOTE:

The following list refers to items in Fig. 64 .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 64: Exploded View Of Sill Panel Trim Strip (Convertible)
Courtesy of VOLKSWAGEN OF AMERICA, INC.


SILL PANEL TRIM STRIP (CONVERTIBLE), REMOVING AND INSTALLING

Removing

z

Remove release lever.

z

Remove screw -5- and spreader nut -6-.

z

Remove side panel trim. See SIDE PANEL TRIM, REMOVING AND INSTALLING .

z

Unclip sill panel trim strip -1- upward.

Fig. 65: Removing Sill Panel Trim Strip (Convertible)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

NOTE:

z

Check clips - 2 - before installing sill panel trim strip and replace as
necessary.

z

Make sure seal -8- is seated correctly after installing sill panel trim strip.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



1998-2004 ACCESSORIES & EQUIPMENT

Seats - Frames - New Beetle

SEATS FRONT

TOOLS

Special tools, workshop equipment, testers, measuring instruments and auxiliary items required

z

VAS 5094 Airbag adapter

Fig. 1: Identifying Special Tools (VAS 5094 Airbag Adapter)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

FRONT SEATS, REMOVING AND INSTALLING

Removing

z

Slide seat forward.

New version

z

Unclip cover cap -10- from inner seat rail and remove bolt -9-. Unclip rear of cover strip -8- arrow -A-

WARNING:

Before working on electrical system: Disconnect battery Ground (GND)
strap. See BATTERY, DISCONNECTING AND RECONNECTING .

NOTE:

z

The removal and installation procedures may have to be modified slightly
depending on equipment variants.

z

Obtain radio unit code before disconnecting battery.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle
