and take off to rear arrow -B-.

z

Unclip cover cap -2- from outer seat rail and remove bolt -3-. Unclip rear of cover strip -4- arrow -C- and
take off to rear arrow -D-.

Fig. 2: Identifying Front Seat Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Older version

z

Unclip rear of cover strip -1- from inner seat rail arrow -A- and pull off arrow -B-.

z

Unclip rear of cover strip -5- from outer seat rail arrow -C- and pull off arrow -D-.

Fig. 3: Identifying Front Seat Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Continuation for all models

z

Slide seat to rear.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



z

Remove bolts -6- (23 N.m) or nuts -7- (23 N.m).

z

Slide seat to rear out of guide rails.

Fig. 4: Identifying Front Seat Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect side airbag connection -1- from coupling station -2-.

Fig. 5: Disconnecting Side Airbag And Seat Heater Connection From Coupling Station
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect seat heater connection -3- from coupling station, if part of original equipment.

z

Install connector -4-(airbag adapter VAS 5094) into connector housing -5-.

NOTE:

Technician must be electrostatically discharged before disconnecting the
igniter and ground wiring (by briefly touching door lock striker or vehicle body).



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



Installing

Install in reverse order of removal.

See appropriate airbag article in RESTRAINTS.

FRONT SEAT BACKREST, ASSEMBLY OVERVIEW

1. Seat trim, right

2. Bolt for trim, right

3. Cover cap, right

4. Seat

5. Backrest

6. Cover cap, left

7. Adjusting knob (backrest)

8. Cover cap

z

Qty. 2

9. Bolt/screw

z

Qty. 2

10. Adjustment lever (seat height)

11. Seat trim, left

12. Bolt for trim, left

NOTE:

z

After reconnecting battery, ensure the vehicle equipment (radio, clock,
electric windows) is checked as per Workshop manual and/or Owner's
manual. See BATTERY, DISCONNECTING AND RECONNECTING .

z

If the Airbag Malfunction Indicator Lamp (MIL) -K75- signals a malfunction
after installation is complete, then the DTC memory must be erased and
interrogated again with V.A.G 1551.

NOTE:

The following list refers to items in Fig. 6 .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



Fig. 6: Identifying Front Seat Backrest Assembly And Trim
Courtesy of VOLKSWAGEN OF AMERICA, INC.

FRONT SEAT BACKREST, REMOVING AND INSTALLING

Removing

z

Remove seat, see FRONT SEATS, REMOVING AND INSTALLING .

z

Pull off adjustment knob -7-. See Fig. 7 .

Fig. 7: Removing Front Seat Backrest
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unclip cover caps - 8 - (Qty. 2) and remove bolts - 9 - (Qty. 2) and remove adjustment lever - 10 -.

z

Remove bolt - 2 - and pull off trim -1-.

NOTE:

The removal and installation procedures may have to be modified slightly
depending on equipment variants.
