Volkswagen New Beetle. Manual - part 520





Fig. 55: Removing Securing Screws From Sealing Parts Of Plenum Chamber
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

CENTER CONSOLE STORAGE NET, REMOVING AND INSTALLING

Removing

z

Unhook net -2- and remove net anchorage -1- screws

Fig. 56: Removing Net Anchorage Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

INSTRUMENT PANEL HANDLE, REMOVING AND INSTALLING

Removing



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



z

Pull off covers -1-.

z

Remove screws -2- and take handle -3- off instrument panel.

Fig. 57: Removing Handle From Instrument Panel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

HANDLE WITH MOBILE TELEPHONE/CELL PHONE RETAINER (INSTRUMENT PANEL),
REMOVING AND INSTALLING

Removing

z

Remove screws -3- and -4- from mobile telephone/cell phone retainer

z

Take off mobile telephone/cell phone retainer -5-.

z

Remove cover -2-.

z

Remove screws -1- and remove left retaining plate -6-. Take handle -7- off instrument panel.

Fig. 58: Removing Handle With Mobile Telephone/Cell Phone Retainer (Instrument Panel)



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

ROOF HANDLE, REMOVING AND INSTALLING

Removing

z

Open handle -1- downward.

z

Pry cover -2- upward using a screwdriver and fold open.

z

Unscrew Phillips screws -3- and remove handle -1-.

Fig. 59: Removing Roof Handle
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

HOLD STRAPS, REMOVING AND INSTALLING

Removing

z

Pry off cover cap -1-.

z

Remove screw -2-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 60: Removing Hold Straps Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Slide cover -1- downward.

z

Remove screws -2- and take off hold strap.

Fig. 61: Removing Hold Strap
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

SILL PANEL TRIM

SILL PANEL TRIM, ASSEMBLY OVERVIEW

NOTE:

The sill panel trim strip is partially covered at front by the A-pillar lower trim and
at rear by the side panel trim. Retaining clips for these panels seat in the cut-



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle
