Fig. 45: Opening Eyeglass Compartment And Removing Cover (On Roof Liner Above Windshield -
Sedan Only)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull eyeglass compartment insert toward vehicle interior.

z

Remove screws -1- and -3-.

z

Take eyeglass compartment off roof liner.

Eyeglass compartment on driver's side (on roof liner - Sedan only)

z

Open eyeglass compartment -1- downward.

z

Pry cover -2- upward using a screwdriver and fold open.

z

Remove Phillips screws -3- and remove eyeglass compartment -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 46: Opening Eyeglass Compartment (On Roof Liner On Driver's Side - Sedan Only)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

FRONT ARMREST, REMOVING AND INSTALLING

Removing

z

Unclip trim -3- from center armrest -1-.

z

Remove screw -2- (18 N.m) and remove center armrest.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 47: Removing Trim From Center Armrest
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

ARMREST LID, REMOVING AND INSTALLING

Removing

z

Open armrest lid -1-.

z

Press armrest lid -1- in direction of arrow B.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 48: Opening Armrest Lid
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Verify any existing damage of armrest lid base -A-.

z

Install in reverse order of removal.

SUN VISOR, REMOVING AND INSTALLING

Removing

z

Unhook sun visor -1- from mounting -2-.

z

Pry off cover caps -6-.

z

Remove screw -5-.

z

Release sun visor mounting -4- from mounting and separate connection -3-.

z

Pry off cover caps -7-.



2003 Volkswagen New Beetle GLS
