Volkswagen New Beetle. Manual - part 516





Fig. 34: Removing Glove Box Screws
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove glove box -1-.

z

Disconnect glove box lighting connections.

Installing

Install in reverse order of removal.

GLOVE BOX LOCK CYLINDER, REMOVING AND INSTALLING

z

In order to avoid damage, cover marked area of flaps -1- and -2-, e.g. with an adhesive tape.

z

Cover marked area of water pump pliers -3- with adhesive tape in order to avoid damage of the glove
box.

Fig. 35: Covering Marked Area Of Flaps With An Adhesive Tape
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Removing

z

Insert ignition key -1- in the lock cylinder -2-.

z

Press lock cylinder -in direction of -arrow-outward the handle -3- with water pump pliers.

Installing

z

Press lock cylinder into the handle opening until it audibly engages.

Fig. 36: Pressing Glove Box Lock Cylinder Into The Handle
Courtesy of VOLKSWAGEN OF AMERICA, INC.

GLOVE BOX LID, REMOVING AND INSTALLING

Removing

z

Remove glovebox. See GLOVE BOX, REMOVING AND INSTALLING .

z

Press plastic bolt from left side with pliers and remove in direction of -arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 37: Pressing Plastic Bolt From Left Side With Pliers
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Use screw driver to remove bolts -1- from hinge.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 38: Removing Bolts From Glove Box Hinge
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove lock cylinder. See GLOVE BOX LOCK CYLINDER, REMOVING AND INSTALLING .

Installing

z

Install in reverse order of removal.

COVER IN DRIVER'S FOOT WELL, REMOVING AND INSTALLING

Removing

z

Remove screws -1-.

z

Pull driver's side footwell cover -2- out of retainers -3-.

Fig. 39: Pulling Driver'S Side Footwell Cover Out Of Retainers
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle
