Volkswagen New Beetle. Manual - part 519





z

Remove screws -8- and remove mounting -2-.

Fig. 49: Removing Sun Visor From Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

SUN VISOR (CONVERTIBLE), REMOVING AND INSTALLING

Removing

z

Unhook sun visor -1- from mounting -2-.

z

Pry off out cover caps -6-.

z

Remove screw -5-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



z

Release sun visor mounting -4- from mounting and separate connection -3-.

z

Pry off cover caps -7-.

z

Remove screws -8- and remove mounting -2-.

Fig. 50: Removing Sun Visor From Mounting (Convertible)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING

Removing

z

Slide plenum chamber center cover -1- forward out of its locking device and take off of dash panel -
arrow-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 51: Sliding Plenum Chamber Center Cover
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove screws -1- (Qty. 3).

Fig. 52: Removing Screws Under Plenum Chamber
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lift left-hand plenum chamber cover -1- in the center of the instrument panel -arrow A-, this action
unclips the panel (front and rear edges are clipped).



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 53: Lifting Left-Hand Plenum Chamber Cover In Center Of Instrument Panel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull cover -1- toward center of instrument panel and out of retainers in A-pillar -arrow B-.

z

Lift right-hand plenum chamber cover -1- in the center of the instrument panel -arrow A-, this action
unclips the panel (front and rear edges are clipped).

Fig. 54: Lifting Right-Hand Plenum Chamber Cover In Center Of Instrument Panel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull cover -1- toward center of instrument panel and out of retainers in A-pillar -arrow B-.

z

Remove securing screws from the right-hand sealing part -1- or the left-hand sealing part -2- and take
sealing part off plenum chamber upward.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle
