Volkswagen New Beetle. Manual - part 2485





Fig. 165: Exploded View Of Differential Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pressing tapered roller bearing outer race out of clutch housing



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 166: Pressing Tapered Roller Bearing Outer Race Out Of Clutch Housing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pressing tapered roller bearing outer race into clutch housing

z

For transmissions with springs behind flange shafts, first remove mounting sleeve for flange shaft seal.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 167: Pressing Tapered Roller Bearing Outer Race Into Clutch Housing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

No shim is installed in the clutch housing end.

Pulling off tapered roller bearing inner race



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 168: Pulling Off Tapered Roller Bearing Inner Race
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Before installing extractor position press piece 40-105 on differential housing.

NOTE:

Both tapered roller bearing inner races are pulled off the differential
housing in the same way.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
