2. Hex bolt z 25 N.m (18 ft lb) 3. Banjo union bolt z 38 N.m (28 ft lb) 4. Pressure line 5. Sealing rings z Always replace 6. Suction hose 7. Spring-type clip 8. Power steering pump z Checking delivery pressure. See POWER STEERING PUMP, RESERVOIR, HYDRAULIC z Before installing fill with oil Note POWER STEERING PUMP, RESERVOIR, HYDRAULIC 9. Belt pulley 10. Hexsocket head bolt z 25 N.m (18 ft lb) 11. Ribbed belt z Mark the direction of travel with a crayon or marker before removing. Reinstalling a used belt in z When installing the belt, make sure that it is correctly seated in the pulleys. z Application. See Parts catalog z Removing and belt routing See RIBBED BELT, REMOVING AND INSTALLING in appropriate ENGINE MECHANICAL z Checking condition See CHECKING CONDITION in RIBBED V-BELT, CHECKING CONDITION article 12. Tensioner for ribbed belt
2003 Volkswagen New Beetle GLS 1998-2004 STEERING Steering - New Beetle
|
