Volkswagen New Beetle. Manual - part 2097





Fig. 80: Identifying Securing Pressure Line On 6-Speed Manual Transmission 02M
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Securing pressure line on automatic transmission 01M

1. Securing bolt on starter

2. Hex nut

z

22 N.m (16 ft lb)

3. Mounting bracket

4. Hex bolt

z

22 N.m (16 ft lb)

5. Mounting bracket

6. Pressure line

Fig. 81: Identifying Securing Pressure Line On Automatic Transmission 01M

NOTE:

The following list refers to items in Fig. 81 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

Disassembling and assembling reservoir

1. Cap with dip stick

z

Oil level: between MIN. and MAX marks; Engine temperature approx. 50°C

z

Arrow A: oil level with engine cold

z

With engine cold, oil level must not rise above MIN. marking

z

Check oil level with cap bolt on

z

Open cap with e.g. a bar

2. Spring-type clip

3. Return hose

4. Longitudinal member right side

5. Nut

z

10 N.m (7.4 ft lb)

6. Mounting bracket

7. Suction hose

8. Engine mounting

9. Reservoir

10. 10-Hex bolt

z

10 N.m (7.4 ft lb)

Fig. 82: Disassembling And Assembling Reservoir
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Securing pressure line and suction hose

NOTE:

The following list refers to items in Fig. 82 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



1. Power steering pump

z

Checking delivery pressure. See POWER STEERING PUMP, RESERVOIR, HYDRAULIC
LINES


z

Before installing fill with oil. See Note. See POWER STEERING PUMP, RESERVOIR,
HYDRAULIC LINES


2. Spring-type clip

3. Suction hose

4. Hex socket head bolt

z

10 N.m (7.4 ft lb)

5. Nut

z

10 N.m (7.4 ft lb)

6. Hex socket head bolt

z

10 N.m (7.4 ft lb)

7. Mounting bracket

8. Banjo union bolt

z

38 N.m (28 ft lb)

9. Pressure line

10. Sealing rings

z

Always replace

11. Bumper carrier

12. Rip tube radiator

13. Radiator

14. Longitudinal member

15. Return hose

16. Spring-type clip

17. Hex bolt

z

9 N.m (80 in lb)

z

New Beetle Sedan: M6x25

z

New Beetle Convertible: M8x25

NOTE:

The following list refers to items in Fig. 83 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 83: Identifying Securing Pressure Line And Suction Hose
Courtesy of VOLKSWAGEN OF AMERICA, INC.

POWER STEERING PUMP WITH HYDRAULIC LINES, VEHICLES WITH AUTOMATIC
TRANSMISSION 09G, ASSEMBLY OVERVIEW

Disassembling and assembling instructions to secure pressure line and suction hose on the power steering
pump. See SECURING PRESSURE LINE AND SUCTION HOSE ON THE POWER STEERING PUMP

Disassembling and assembling instructions to secure pressure line and suction hose on automatic transmission.
See SECURING PRESSURE LINE AND SUCTION HOSE ON THE AUTOMATIC TRANSMISSION
09G


1. Reservoir

Disassembling and assembling instructions. See DISASSEMBLING AND ASSEMBLING
RESERVOIR


2. Power steering pump

z

Checking delivery pressure. See POWER STEERING PUMP, RESERVOIR, HYDRAULIC
LINES


z

Before installing fill with oil Note. See POWER STEERING PUMP, RESERVOIR,
HYDRAULIC LINES


3. Pressure hose/line mounting

z

On the power steering pump

4. Securing suction hose

z

On the power steering pump

5. Suction hose

6. Securing suction hose

NOTE:

The following list refers to items in Fig. 84 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle
