On cylinder block

7. Pressure line

8. Pressure hose/line mounting

On automatic transmission 09G

Disassembling and assembling instructions. See SECURING PRESSURE LINE AND SUCTION
HOSE ON THE POWER STEERING PUMP


9. Securing return hose

On automatic transmission 09G

Disassembling and assembling instructions. See SECURING PRESSURE LINE AND SUCTION
HOSE ON THE POWER STEERING PUMP


10. Return hose

Fig. 84: Identifying Power Steering Pump With Hydraulic Lines (Vehicles With Automatic Transmission
09G)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Securing pressure line and suction hose on the power steering pump

1. Banjo union bolt

z

38 N.m (28 ft lb)

2. Sealing rings

z

Always replace

3. Pressure line

NOTE:

The following list refers to items in Fig. 85 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



4. Power steering pump

z

Checking delivery pressure. See POWER STEERING PUMP, RESERVOIR, HYDRAULIC
LINES


z

Before installing fill with oil Note. See POWER STEERING PUMP, RESERVOIR,
HYDRAULIC LINES


5. Sleeve

z

Power steering pumps for the company Kayaba only

6. Clamp

7. Hexagon bolt

z

22 N.m (16 ft lb)

8. Spring-type clip

9. Suction hose

10. Mounting bracket

z

On the cylinder block

11. Mounting bracket

12. Hex bolt

z

40 N.m (30 ft lb)



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 85: Identifying Pressure Line And Suction Hose
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Securing pressure line and suction hose on the automatic transmission 09G

1. Automatic transmission

2. Twin bolt

z

40 N.m (30 ft lb)

3. To reservoir

4. Hex nut

z

22 N.m (16 ft lb)

5. Return hose

NOTE:

The following list refers to items in Fig. 86 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



6. From the steering gear

7. From the power steering pump

8. Pressure line

9. Hex bolt

z

22 N.m (16 ft lb)

10. To steering gear

Fig. 86: Identifying Pressure Line And Suction Hose On Automatic Transmission 09G
Courtesy of VOLKSWAGEN OF AMERICA, INC.

POWER STEERING PUMP IN LOWER SECTION, ASSEMBLY OVERVIEW

Vehicles with power steering pump in lower section

1. Mounting bracket

NOTE:

The following list refers to items in Fig. 87 .



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle
