Volkswagen New Beetle. Manual - part 2017





Fig. 47: Removing Clutch Plate
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Clutch pulley, removing

z

Remove circlip, see A/C CLUTCH -N25-, SERVICING (SANDEN)

z

Attach commercially available 2 arm puller -A- on shoulder -B- and pull off pulley.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



Fig. 48: Removing Clutch Pulley
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Clutch coil, installing

z

Install coil on compressor.

z

Locate locking pin on coil -A- into recess -C-.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



Fig. 49: Installing Clutch Coil
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Clutch plate gap, checking

z

Gap: 0.4 - 0.8 mm (0.015 - 0.023 in)



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



Fig. 50: Checking Clutch Plate Gap
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Determine "Dimension 1"

z

Using depth gauge -1-, measure gap between top of clutch plate -3- and clutch pulley -2- at three equally
spaced locations (measurement must not deviate). See Fig. 50 .

Determine "Dimension 2"

z

If compressor is installed in vehicle, disconnect compressor electrical connector -4- from vehicle wiring
harness. See Fig. 50 .

z

Using a jumper wire, energize the clutch coil by applying 12V to connector -A- (battery terminal B+). If
compressor is removed from vehicle, compressor must be grounded.

z

With clutch energized, measure gap between pulley -2- and clutch plate -3- with depth gauge -1-.

The allowable gap (0.4-0.8 mm / 0.015-0.023 in) is the difference between "Dimension 1" and
"Dimension 2".

NOTE:

z

Gap must be within tolerance around entire circumference.
