Fig. 44: Identifying Components Of A/C Clutch -N25- (Sanden)
Courtesy of VOLKSWAGEN OF AMERICA, INC.


1. Hex nut

z

Self-locking

z

Always replace

z

15 N.m (11 ft. lb)

z

Removing and installing, See Hex nut, removing and installing

2. Clutch plate

z

Removing, See A/C clutch -N25-, removing and installing

z

Checking clutch plate gap, See Clutch plate gap, checking

3. Shims

z

Used to adjust gap between clutch plate and pulley

z

Gap: 0.4-0.8 mm (0.015-0.023 in)

4. Circlip

z

Always replace

„

Install correctly: Flat side faces compressor.

z

Ensure correct seating in groove

5. Clutch pulley

z

Removing, See Clutch pulley, removing

6. Circlip

z

Replacing

„

Install correctly: Flat side faces compressor

z

Ensure correct seating in groove

7. Clutch coil

z

Installing, See Clutch coil, installing

8. Connector clip

z

With screw

9. Harness clip

10. Harness clip

11. Screw

12. Compressor

NOTE:

The following list refers to items in Fig. 44 .

NOTE:

A thermo-fuse integrated into the clutch coil protects the A/C clutch in the
event of overheating (e.g.: due to a binding compressor). The clutch coil
circuit is interrupted.



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



13. Threaded bushing

A/C CLUTCH -N25-, REMOVING AND INSTALLING

Special tools, testers, measuring instruments and auxiliary items required

z

Tool 3212 A (or equivalent)

z

Two arm puller

z

Three arm puller

z

Depth gauge

z

Torque wrench (5-50 N.m)



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



Fig. 45: Identifying Special Tool 3212
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Notes

z

It is not necessary to discharge the refrigerant system to remove and install the A/C clutch.

z

If A/C clutch is to be removed with compressor installed, first do the following:

{

Remove ribbed belt. See RIBBED BELT, REMOVING AND INSTALLING .

{

Remove intercooler (engine code ALH only). See CHARGE AIR COOLER COMPONENTS,
REMOVING AND IN
 .



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle



z

If A/C clutch is to be removed with compressor removed, first discharge refrigerant system. See A/C
refrigerant system, discharging
 .

Hex nut, removing and installing

Fig. 46: Removing And Installing Clutch Plate Hex Nut
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tightening torque: 15 N.m (11 ft. lb)

{

Remove hex nut while counter-holding with 3213A or equivalent commercially available 2 hole
pin wrench (with 4 mm pins).

Clutch plate, removing

z

Carefully pry off clutch plate using two large screwdrivers -A-.

Use locally available 2 or 3 arm puller if plate is securely seated (difficult to remove).



2003 Volkswagen New Beetle GLS

1998-2004 HVAC Air Conditioning - New Beetle
