z

Disconnect harness connector from all fuel injectors.

z

Remove fuel rail assembly.

z

Disconnect vacuum hose from fuel pressure regulator.

z

Lift fuel rail with injectors from intake manifold and support

Checking for leaks

z

Initiate Output Diagnostic Test Mode and activate cyl. 1 fuel injector -N30. See COMPONENTS AND
FUNCTIONS, ADAPTING


z

Fuel pump must run.

z

Visually check fuel injector for leaks.

z

Only 1 to 2 drops per minute allowed from each injector when fuel pump is running.

If fuel loss is greater than specified:

z

Switch OFF ignition and replace leaking fuel injector.

Fuel injection quantity, checking

z

Insert injector to be checked in a measuring glass for VAG 1602 Fuel analyzer.

z

Connect one terminal of injector to be tested to engine Ground using jumper wires from VW 1594
Adaptor kit.

NOTE:

This check allows the fuel pump to operate without running the engine. The
Closed Throttle Position switch must remain closed for this check, otherwise
the selected injector will inject 5 times.

NOTE:

When installing, note the following:

z

Replace O-rings on all injectors after first moistening the new O-ring with
clean engine oil.

z

Vertically insert injectors into the correct position in the fuel rail and
secure with retaining clips.

z

Fit fuel rail with secured injectors onto intake manifold and press in
evenly.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 30: Connecting Injector Terminal And Jumper Wire To VAG 1348/3A Remote Control Using
VAG 1348/3-2 Adapter Cable

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect other injector terminal and jumper wire to VAG 1348/3A remote control using VAG 1348/3-2
adapter cable

z

Connect alligator clip to Battery positive (+).

z

Initiate Output Diagnostic Test Mode and activate cyl. 1 fuel injector -N30-. See COMPONENTS AND
FUNCTIONS, ADAPTING


z

Fuel pump must run

z

Operate remote control VAG 1348/3A for 30 seconds.

z

Repeat check for other injectors on this cylinder bank using separate measuring containers.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

After all injectors have been activated, place measuring containers on a horizontal surface and compare
injected quantities.

z

Specification: 85 to 105 ml per injector

If the measured quantity of one or more injectors are above or below the specification:

z

Replace faulty fuel injector(s). See ENGINE CODES AVH, AZG item -10-

Install fuel injectors in reverse order of removal procedure. When installing, note the following:

z

Replace O-rings on all injectors after first moistening the new O-ring with clean engine oil.

z

Vertically insert injectors into the correct position in the fuel rail and secure with retaining clips.

z

Fit fuel rail with secured injectors onto intake manifold and press in evenly.

Engine codes AVH, AZG, BDC, BEV, BGD

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

V.A.G 1348/3 Remote control

z

V.A.G 1348/3-2 Adapter

z

V.A.G 1602 Calibration tester

z

V.A.G 1594 A Adapter set

z

Test box V.A.G 1598/31



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 31: Identifying Special Tools, Equipment And Measuring Instruments (Engine Codes AVH,
AZG, BDC, BEV And BGD)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirements

z

Fuel pressure must be OK, checking. See FUEL PRESSURE REGULATOR AND HOLDING
PRESSURE, CHECKING
 .

Work sequence

z

Remove inner plenum chamber cover, left:

WARNING:

Fuel system is under pressure! Before opening the system remove fuse
28 and place a cloth around the connection. Then release pressure by
carefully loosening the connection.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)
