Volkswagen New Beetle. Manual - part 1580





Fig. 25: Pressing Tabs Outward For Releasing Pins For Spreader Rivet Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove cylinder head cover. See ENGINES WITH STEEL CYLINDER HEAD COVER or see
ENGINES WITH ALUMINUM CYLINDER HEAD COVER .

Continuation for all engines

z

Remove rear bolts from warm air deflector plate and front bolts of intake manifold lower part.

z

Carefully remove intake manifold upper part.

NOTE:

The intake manifold upper part complete with throttle valve control module
can only be removed when the cylinder head cover has been removed.

NOTE:

z

Seal the intake ports in the intake manifold lower section with clean cloths.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Installing

Installation is performed in the reverse order. When installing, note the following:

z

Carefully seat intake manifold upper part onto its original position on warm air collector plate.

Engine codes BDC, BGD

z

Install cylinder head cover; tightening torques. See ENGINES WITH STEEL CYLINDER HEAD
COVER
 or see ENGINES WITH ALUMINUM CYLINDER HEAD COVER .

z

Slide intake manifold upper part carefully onto intake manifold supports on intake manifold lower part.

z

Press tabs -1- carefully outward. Then press intake manifold upper part back onto intake manifold lower
part by moving it back and forth until it seats on limit stop.

z

To remove the intake manifold upper part, remove the throttle valve
control module and vacuum hoses from the brake servo.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 26: Pressing Tabs Outward And Intake Manifold Upper Part Back Onto Intake Manifold
Lower Part

Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

Install spreader (split) rivets. See Fig. 9 , item - 9 -.

z

Install bolts to intake manifold upper part on intake manifold support of warm air collector (arrows);
tightening torques. See Fig. 9 , item -14-.

Fig. 27: Tightening Bolts To Intake Manifold Upper Part On Intake Manifold Support Of Warm
Air Collector

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install upper bolts on intake manifold (arrows), tightening torques.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)
