Volkswagen New Beetle. Manual - part 1579





Fig. 22: Identifying 3094 Hose Clamps
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

CAUTION: When performing repair work, especially due to the confined conditions in

the engine compartment, pay attention to the following:

z

Route all types of lines (e.g. for fuel, hydraulics, EVAP system,
coolant, refrigerant, brake fluid and vacuum) as well as electrical
wiring so that the original positions are restored.

z

Ensure sufficient clearance to all moving or hot components.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

With ignition switched off disconnect battery Ground strap.

z

Remove engine cover.

z

Release pressure in coolant circuit by opening coolant expansion tank cap.

z

Remove air cleaner with intake hose and Mass Air Flow (MAF) sensor -G70-. See AIR CLEANER,
DISASSEMBLING AND ASSEMBLING
 .

z

Clamp off coolant hose from Throttle valve control module -J338- (with for example V.A.G 3094).

z

Ensure following components are disconnected from coolant hoses:

z

Top of expansion tank

z

Throttle valve control module -J338-

z

Ensure following components are disconnected from electrical connections:

Engine codes BDC, BGD

z

Intake manifold change-over valve -N156-

Continuation for all engines

z

Positive Crankcase Ventilation (PCV) heating element -N79-

z

Throttle valve control module -J338-

z

Ensure following components are disconnected from breather or vacuum hoses:

Engine codes BDC, BGD

z

Intake manifold change-over valve -N156-

z

Vacuum line T-piece from Intake manifold changeover valve -N156-

Continuation for all engines

z

EVAP canister purge regulator valve -N80- to intake manifold upper part

z

EVAP canister to intake manifold upper part

z

Injector breather lines

z

Brake servo vacuum line

NOTE:

z

During the further course of work the battery Ground strap must be
disconnected. Therefore, please check whether a coded radio is installed.
Obtain the radio code first if necessary.

z

Observe the notes on COOLING SYSTEM, SERVICING .

WARNING:

Steam can be released when removing the cap from the expansion
tank. Cover the cap with a cloth and open it carefully.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Engine codes AEG, AVH, AZG, BDC

z

On fuel pressure regulator

Engine codes BDC, BGD

z

Remove bolts (arrows) from intake manifold upper part -1- on intake manifold support of warm air
collector -2-. See Fig. 23 . See Fig. 9 , item - 14 -.

Fig. 23: Removing Bolts From Intake Manifold Upper Part On Intake Manifold Support Of Warm
Air Collector (Engine codes BDC, BGD)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove upper bolts on intake manifold (arrows). See Fig. 24



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 24: Removing Upper Bolts From Intake Manifold (Engine codes BDC, BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove spreader (split) rivets. See Fig. 9 , item - 9 -.

z

Press tabs -1- as illustrated in Fig. 25 , carefully outward so that pins for spreader (split) rivet mounting -
2- are free. Simultaneously, move intake manifold upper part back and forth until it can be disconnected
on exhaust side.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)
