z To remove from flange and fuel filter press release button on connecting piece 29. Return pipe z Blue or blue markings z Clipped onto side of fuel tank z Check securely seated z To remove from flange press release button on connecting piece z From fuel return pipe on fuel rail See Fuel Rail With Injectors, Disassembling And Assembling . 30. Connector z Black, 4-pin z For Fuel Gauge sensor -G- and Fuel Pump -G6- 31. 10 N.m Fig. 1: Exploded View Of Fuel Supply System Components Installation Position Of Fuel Delivery Unit Flange
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Fuel System - New Beetle, 1.8L (APH, AWV & AWP)
|
