1998-2004 ENGINE PERFORMANCE

Fuel Supply, 1.9L 4-CYL. ALH & BEW - New Beetle

FUEL SUPPLY

ACCELERATOR LINKAGE

Accelerator linkage, servicing

1. Mounting bracket

2. Connector

z

Black, 6-pin

3. 10 Nm

4. Throttle Position (TP) Sensor -G79- and Sender -2- for accelerator pedal position -G185-*

z

Not adjustable.

z

Throttle Position (TP) sensor communicates the driver's intentions to the control module for Diesel-
Direct fuel injection system

z

To remove sensor, remove cover in footwell

z

Checking. See THROTTLE POSITION (TP) SENSOR, CHECKING .

5. Bracket

z

for footwell cover

z

for model year 2002 and up

z

clipped in at Throttle Position (TP) Sensor

6. Bracket

z

for footwell cover

z

for up to model year 2001

z

clipped in at Throttle Position (TP) Sensor

NOTE:

Components marked with * are checked via On Board Diagnostic (OBD). See
DIAGNOSTIC MODE 3: CHECK DTC MEMORY .

NOTE:

The following list refers to Fig. 1 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Fuel Supply, 1.9L 4-CYL. ALH & BEW - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Fuel Supply, 1.9L 4-CYL. ALH & BEW - New Beetle



Fig. 1: Identifying Accelerator Linkage Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Throttle Position (TP) sensor, checking

Recommended special tools and equipment

z

VAG1526 multimeter or VAG1715 multimeter

z

VAG1594 connector test kit

z

Wiring diagram

Test requirement

z

The respective fuses of Diesel-Direct fuel injection system must be OK:

Fig. 2: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Function

Both the Throttle Position (TP) Sensor -G79- and the Sender -2- for accelerator pedal position -G185- are
located at the accelerator pedal and communicate the driver's intentions to the control module for Diesel-Direct

NOTE:

Fuse holder is located behind access panel at far left end of dash.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Fuel Supply, 1.9L 4-CYL. ALH & BEW - New Beetle



fuel injection system completely independently of each other. Both sensors are installed in one housing.

Test sequence

z

Remove footwell cover (driver's side).

z

Disconnect 6-pin connector from Throttle Position (TP) Sensor.

z

Switch ignition on.

Checking voltage supply and wiring to control module

z

Connect multimeter to the following connector terminals for voltage measurement.

Terminal 1 + Ground (GND)

Terminal 1 + 5

Terminal 2 + Ground (GND)

Terminal 2 +3

Specified value: at least 4.5 V

Fig. 3: Identifying Throttle Position And Accelerator Position Sensor Harness Connector
Terminals

Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Switch ignition off.

If specified values are not obtained:

z

Connect test box to control module wiring harness. See TEST BOX, CONNECTING FOR WIRING
TEST
 .

Vehicles with 80-pin control module

NOTE:

When servicing terminals in the harness connector for the Throttle Position (TP)
Sensor, use only gold-plated terminals.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Fuel Supply, 1.9L 4-CYL. ALH & BEW - New Beetle



z

Check for open circuits in wires between test box and connector according to wiring diagram.

Terminal 2 + socket 11

Terminal 3 + socket 23

Terminal 4 + socket 24

Terminal 5 + socket 12

Terminal 6 + socket 25 Vehicles with automatic transmission

Terminal 1 + socket 8

Wire resistance: max. 1.5 ohm

Fig. 4: Identifying Throttle Position And Accelerator Position Sensor Harness Connector
Terminals (80-Pin ECM)

Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with 121-pin control module

z

Check for open circuits in wires between test box and connector according to wiring diagram.

Terminal 2 + socket 12

Terminal 3 + socket 50

Terminal 4 + socket 69

Terminal 5 + socket 70

Terminal 6 + socket 51 Vehicles with automatic transmission



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Fuel Supply, 1.9L 4-CYL. ALH & BEW - New Beetle
