Fig. 187: Scan Tool Display - A/C System Signals (5 Of 6) z Press --> button. Display will appear as shown: Fig. 188: Scan Tool Display - A/C System Signals (6 Of 6) z A/C compressor shut-off is checked via Output DTM. z The A/C compressor must stop within 5 secs, (visual check) then start approx. every 5 secs. and then If A/C compressor NOT switched OFF z Proceed with Function 03: Output DTM, until completed. z Press -0- and -6- buttons to select Function 06: "End output". z Press -Q- button to enter input.
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
|
